Appendix
| EMEX Power detailed specification
2.0 Central inverter system
The system should offer the following standard
features as summarised below and further detailed in
sections 3.0, 4.0, 5.0, 6.0 & 7.0:
1. True AC/AC 50/60Hz output
2. Ability to use standard proprietary AC distribution
and protection devices on outgoing circuits
3. Rated for any load power factor, zero to unity, at
any output power up to the maximum rated KVA
4. Compatibility with addressable test package using
EMEX technology
5. Excellent overload capability in full emergency
mode: 200% for 10 seconds without reduction in
output voltage
6. Excellent recharge capability – 80% after
12 hours following rated discharge
7. MCB protection throughout – no fuses
8. EMEX Power true modular construction with
common spares (inverter, charger, control PCB,
and system interface common across the full
system range)
9. Individual MCB protection for each module
– AC and DC circuits
10. Individual cooling fans for all modules with
on-demand operation (not continuously running)
11. Split parallel charger above 10 amps – enhanced
integrity with the ability to operate with one
or more charger modules isolated (subject to
increased recharge time)
12. Integral maintenance bypass facility (ability
to support output load in bypass mode whilst
maintenance is performed)
13. Temperature compensated charger
14. Comprehensive display
15. Charger and inverter alarm pack
16. Momentary “push to test” button
17. Fire alarm interface
18. Final exit interlock
19. Internal and external MCB monitoring
20. Local/remote maintained circuit control
21. Sub-circuit monitor connection
22. Two sets of volt–free alarm relay contacts
23. Inverter-inhibit engineers’ switch
24. Remote Alarm Unit option
25. Easy front panel access
26. Inter-cabinet trunking for battery cables
27. Fork-lift plinth
28. Lifting eyes for crane lift as standard
29. Cabinet levelling feet available
30. Installation pack with tools included
31. Detailed instruction manual
32. Transfer time both directions max. 0.5 seconds
3.0 Static inverter specification
LED Indications
Mains healthy
Green
Maintained circuit on
Green
Battery high volts
Amber
Battery low volts
Amber
Supply from battery
Red
Charge fail
Red
System fault
Red
Common alarm
Red
Battery discharged
Red
System inhibited
Red
Metering
DC metering
Combined digital battery voltage
and charge/discharge current
AC metering
Combined digital AC output
Voltage and current
Alarms
Alarm outputs
Two sets of voltage free contacts
1A @ 230V AC / 1A @ 28V DC
Local audible alarm (can be
muted)
Controls
Final exit interlock
Requires volt-free contact
Sub-circuit monitor
24V control loop
Maintained circuit control 24V control loop
Fire Alarm Control
12/24V DC from fire panel
Remote MCB monitoring 24V control loop
Changeover device
Four pole contactor to
BS 5424 and EN 60947
Inverter Module(s)
Nominal output
220V – 240V 50Hz AC
Rating
1.5KVA or 3KVA rating with
Master or Slave configuration
Overload
120% continuous with full output
150% for 1 minute with full
output
200% for 10 seconds with full
output
Short Circuit
350% for 5 seconds
Cooling
Integral fan
(on-demand operation)
Protection
AC 2 pole type D
DC 2 pole type B
Module Dimensions 360mm x 170mm x 575mm
Handling
Recessed handles front and rear
Weight
50kg
1.0 General standards
The Emergency Lighting System and all of its components shall be manufactured and certified to meet
the requirements of BS EN 50171, ICEL 1009, and CE. The system shall be CE marked.
