Dimensions
For Serenga Sun-Lite spacing data, see page 85.
For slave control module drawing, see page 91.
For further information on Naveo and IR2 emergency luminaire testing
formats, see pages 73 - 77 or contact Emergi-Lite.
Recessed unit
Order Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output
Operation /
Duration
(hrs)
Recharge
Period
Colour Environment Weight
SER-DA-RM3
220 - 240 Vac, 50 Hz
2 x 1 W LED
60 mA
56 lumens
M3
24 hours
0 -
25
°C 1.1 kg
SER-DAS-RM3
220 - 240 Vac, 50 Hz
2 x 1 W LED
60 mA
56 lumens
M3
24 hours
0 -
25
°C 1.1 kg
SER-DAB-RM3
220 - 240 Vac, 50 Hz
2 x 1 W LED
60 mA
56 lumens
M3
24 hours
0 -
25
°C 1.1 kg
SER-DA-R230
85 - 240 Vac, 50/60 Hz
2 x 1 W LED
30 mA
56 lumens
230 V
-
0 - 40 °C 1.0 kg
SER-DAS-R230
85 - 240 Vac, 50/60 Hz
2 x 1 W LED
30 mA
56 lumens
230 V
-
0 - 40 °C 1.0 kg
SER-DAB-R230
85 - 240 Vac, 50/60 Hz
2 x 1 W LED
30 mA
56 lumens
230 V
-
0 - 40 °C 1.0 kg
SER-DA-R230LTC
85 - 240 Vac, 50/60 Hz
2 x 1 W LED
30 mA
56 lumens
230 V
-
0 - 40 °C 1.1 kg
SER-DAS-R230LTC
85 - 240 Vac, 50/60 Hz
2 x 1 W LED
30 mA
56 lumens
230 V
-
0 - 40 °C 1.1 kg
SER-DAB-R230LTC
85 - 240 Vac, 50/60 Hz
2 x 1 W LED
30 mA
56 lumens
230 V
-
0 - 40 °C 1.1 kg
Accessories
Order Code Description
SER-DBZ5-AL
Trim bezel aluminium (pack of 5)
SER-DBZ5-BR
Trim bezel brass (pack of 5)
SER-DBZ5-SI
Trim bezel silver (pack of 5)
SER-DBZ5-WH
Trim bezel white (pack of 5)
143
Ø68
Ø92
5-20
34
216
78
min.
110
58
max. Ø10 (2x)
For testing and dimmable downlighter options, please contact Emergi-Lite.
Serenga Sun-Lite recessed open area.
Ideal for high specification projects
Excellent alternative to converted downlighters
and 8 Watt fluorescent luminaires
Two LEDs in head unit with separate control
module and battery
Intelligent Self-Test as standard
Polycarbonate downlighter and polyamide
control module
Optional clear clip-on IP40 cover included
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the Netherlands
