www.emergi-lite.co.ukSerenga Sun-Lite surface mounted escape route.
Ideal for high specification projects
Excellent alternative to converted downlighters
and 8 Watt fluorescent luminaires
Light optimised reflector
Ingress rated to IP42 when ceiling mounted
Intelligent Self-Test as standard
Polycarbonate, first-fix enclosure
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the Netherlands
modular & energy efficient
Surface mounted unit
Order Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output
Operation /
Duration
(hrs)
Recharge
Period
Colour Environment Weight
SER-SEM3-11
220 - 240 Vac, 50 Hz 1 x 1 W LED
40 mA
64 lumens
M3
24 hours
5 - 25 °C 2.0 kg
SER-SEM3-33
220 - 240 Vac, 50 Hz 1 x 1 W LED
40 mA
64 lumens
M3
24 hours
5 - 25 °C 2.0 kg
SER-SEM3-22
220 - 240 Vac, 50 Hz 1 x 1 W LED
40 mA
64 lumens
M3
24 hours
5 - 25 °C 2.0 kg
SER-SE230-11
85 - 240 Vac, 50/60 Hz 1 x 1 W LED
50 mA
65 lumens
230 V
-
5 - 35 °C 1.8 kg
SER-SE230-33
85 - 240 Vac, 50/60 Hz 1 x 1 W LED
50 mA
65 lumens
230 V
-
5 - 35 °C 1.8 kg
SER-SE230-22
85 - 240 Vac, 50/60 Hz 1 x 1 W LED
50 mA
65 lumens
230 V
-
5 - 35 °C 1.8 kg
SER-SE230LTC-11
85 - 240 Vac, 50/60 Hz 1 x 1 W LED
50 mA
65 lumens
230 V
-
5 - 35 °C 1.9 kg
SER-SE230LTC-33
85 - 240 Vac, 50/60 Hz 1 x 1 W LED
50 mA
65 lumens
230 V
-
5 - 35 °C 1.9 kg
SER-SE230LTC-22
85 - 240 Vac, 50/60 Hz 1 x 1 W LED
50 mA
65 lumens
230 V
-
5 - 35 °C 1.9 kg
Dimensions
For Serenga Surface Mounted spacing data, see page 85.
For further information on Naveo and IR2 emergency luminaire testing
formats, see pages 73 - 77 or contact Emergi-Lite.
40
162
192
140
152
Ø16 (4x)
For testing and dimmable downlighter options, please contact Emergi-Lite.
