Emergi-Lite Emergency Lighting Product Catalogue

15 / 105

15
Thomas & Betts Ltd., Emergi-Lite, Bruntcliffe Lane, Morley, Leeds, LS27 9LL • Tel: +44 (0)113 281 0600 •
Email: • Web:
Control assembly
Order Code Input Voltage Operation /
Duration (hrs)
Recharge
Period
Environment Weight
SER-M3-003 220 - 240 Vac, 50 Hz M3 24 hours 5 - 25 ºC 0.8 kg
SER-230-003 85 - 240 Vac, 50/60 Hz 230 V - 5 - 40 ºC 0.8 kg
SER-230LTC-003 85 - 240 Vac, 50/60 Hz 230 V - 5 - 40 ºC 0.8 kg
Smart-frame
Order Code Lamp Type Power Consumption
Self-contained
Power Consumption
Slave
Lamp
Output*
Weight Includes
Legend
SER-FS2D 2 x 1 W LED 60 mA 30 mA - 0.9 kg
SER-FS4D 4 x 1 W LED 70 mA 60 mA 27 lumens 0.9 kg
256
218
Ø18 (4x)
35
57
69
274
293
340
Legends
SER-SC012 SER-SC010 SER-SC011 SER-SC013 SER-SC802 SER-SC803
Accessories
Exit sign with curved legend.
2 LED exit sign or 4 LED exit sign with downlighters
Easy to fit modular assembly
High impact polycarbonate body with
aluminium trim
Intelligent Self-Test included as standard
Two surface mount orientations
Designed and manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the Netherlands
Order control assembly, smart-frame, legend and
mounting kit (if required) separately
For testing and dimmable control assemblies, please contact Emergi-Lite.
Legends are screen printed. Euro pictogram legends shown. ISO 7010 format legends are available to order, see page 95 or contact Emergi-Lite.
Order Code Description
SER-BZKIT Recessing kit
SER-RKIT150 Tube suspension kit (0.15 m)
SER-RKIT300 Tube suspension kit (0.3 m)
SER-RKIT500 Tube suspension kit (0.5 m)
SER-RKIT1000 Tube suspension kit (1 m)
Dimensions
modular & energy efficient
* Total output from 2 lower LEDs through lenses.
For Serenga Escape 4 LED spacing data, see page 85.
For accessory drawings, see page 90.
For further information on Naveo and IR2 emergency luminaire testing
formats, see pages 73 - 77 or contact Emergi-Lite.
