Non-metallic conduit systems
Type FLC90/FL90 & T - Adaptaseal
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / CP / PR / PF
IP66
Yes
IP67
Yes
IP68
Yes (2 bar 30mins)
IP69K
Yes
Type FLC90/FL90 - Adaptaseal
90° Elbow Body - Panel Mount Swivel Flange
/
For panel mounting via 2/4 hole fixing & integral face seal
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL) Only
Part No.
Nominal Conduit Size
ASF13/FL/C90 13mm
ASF16/FL/C90 16mm
ASF21/FL/C90 21mm
ASC21/FL/C90 21mm
ASF28/FL/C90 28mm
ASC28/FL/C90 28mm
ASF34/FL/90* 34mm
ASC34/FL/90* 34mm
ASC42/FL/90* 42mm
ASC54/FL/90* 54mm
To order quote part number & body colour, e.g. ASF13/FL/C90/BL
*These sizes are fixed panel mounting - non swivel
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -5ºC to +120ºC
Approvals
Type FLC90/FL90
90° Elbow Fitting
IP Rating
Appropriate Conduit
For use with:
Type PA / PI / CP / PR / PF
IP66
Yes
IP67
Yes
IP68
N/A
IP69K
N/A
Type T - Adaptaseal
Inspection T-Piece
/
For connection to corrugated flexible conduit
Materials:
Polyamide (Nylon) 66 /
Colour:
Black (BL) Only
Part No.
Nominal Conduit Size
ASF10X3/T
10mm
ASF13X3/T
13mm
ASF16X3/T
16mm
ASF21X3/T
21mm
ASC21X3/T 21mm
ASF28X3/T
28mm
ASC28X3/T 28mm
ASF34X3/T
34mm
ASC34X3/T 34mm
To order quote part number & body colour, e.g. ASF10X3/T/BL
Temperature Range
Static Applications: -40ºC to +120ºC
Moving Applications: -5ºC to +120ºC
Approvals
Type T
Inspection T-Piece
