Zone Controllers

L

ON

M

ARK

®

certified individual room controllers for VAV applications (Variable

Air Volume) connected to an external air flow controller (Belimo VAV Com-

pact). The controller keeps a constant temperature in the zone by controlling

the air flow, optional heating stages, and fan in sequence. By using a carbon

dioxide sensor, the air quality can be controlled in the zone. The controller

can be operated stand-alone or within a L

ON

W

ORKS

®

network. PI control with

individual P-band and I-time setting for heating and cooling. Can be moni-

tored and parameters can be set centrally via the central system or remotely

with the TAC Xenta L

ON

W

ORKS

®

Operator Panel.

FUNCTIONAL FEATURES

Various applications:

Single-step control with

setpoint calculation of an

external air flow controller.

Two-step setting with cooling

and heating in sequence.

Heating operation via an

electric reheater or hot water.

Slave function mode of

operation and setpoint for

several slave controllers are

controlled by one master.

Setpoint adjustment via a wall

module with setpoint adjuster

or via a L

ON

W

ORKS

®

network

variable.

Seven modes of operation:

comfort, standby, bypass,

unoccupied, off, slave and

purge mode.

Air quality based adjustments.

Configurable limit values MIN

and MAX air flow limit.

Alarm monitoring high or

low room temperature, open

window, temperature sensor

error, etc.

Occupancy sensor, window

contact and cool-down

protection, CO

2

measurement

input.

SPECIFICATIONS

Operating voltage . . . . . . . . . . . . . . . . 24 V AC ±20%

Power consumption . . . . . . . . . . . . . . . 4 VA

Dimensions. . . . . . . . . . . . . . . . . . . . . . 127 x 126 x 50mm

(5” x 5” x 2”)

Ambient temperature

Operation . . . . . . . . . . . . . . . . . . . . . . 0°C to +50°C (32°F to 122°F)

Storage. . . . . . . . . . . . . . . . . . . . . . . . . –20°C to +50°C (–4°F to 122°F)

Humidity . . . . . . . . . . . . . . . . . . . . . . . max. 90% RH non-condensing

Enclosure rating . . . . . . . . . . . . . . . . . . IP 30

Inputs and outputs

Window contact. . . . . . . . . . . . . . . . . . Digital input

Occupancy sensor . . . . . . . . . . . . . . . . Digital input

Air damper . . . . . . . . . . . . . . . . . . . . . . 0 – 10 VDC

Heating valve . . . . . . . . . . . . . . . . . . . . 2-point output

(102-EF); 0 - 10 VDC (102-VF)

Room temperature . . . . . . . . . . . . . . . . Thermistor input

Air flow . . . . . . . . . . . . . . . . . . . . . . . . 0 – 10 VDC

CO

2

sensor . . . . . . . . . . . . . . . . . . . . . . 0 – 10 VDC

Wall module. . . . . . . . . . . . . . . . . . . . . As selected

For further specifications, see technical data sheet.

DESCRIPTION

0-073-0531-0 TAC Xenta 102-B VAV Controller

0-073-0533-0 TAC Xenta 102-EF VAV Controller electrical reheat

0-073-0535-0 TAC Xenta 102-VF VAV Controller valve reheat

TAC Xenta 102-B, 102-EF,

102-VF VAV Controllers
