Elegance 170 Aluminium
Base unit and cover
code pack
LP1050SG
1 x 2.9m
Elegance 170 Aluminium is a sleek and rounded 170mm
rectangular dado trunking system with a single cover, ideal for
use in office or educational environments where extra
mechanical strength and a higher cable capacity is required.
Product information
170 x 55mm
"C" type section can be used as a single large compartment
section or can be further sub-divided into 2 or 3 compartments
Cat 6, 6a and 7 compliant
Suitable for dado and skirting applications
Pre-punched dividers for quick installation
A range of fabricated fittings
Part M compliant
Compatible with Marshall-Tufflex flush power and data
accessories and standard UK wiring power and accessories
Standard silver-grey RAL 9006 powder coat finish. White
RAL 9016 is also available to order subject to a lead time.
Can be used inconjunction with Conduit and Mini trunking systems
End cap (screws included) Internal bend 90º External bend 90º Slow Flat angle
code pack code pack code pack code pack
LP1030SG
1
LP1020SG
1
LP1026SG
1
LP1040SG
1
Flat tee
code pack
LP1045SG
1
Basic components
Fittings
Can be divided into 2
or 3 compartments
Part M
1 and 2 gang box
assemblies with coloured
flush plates to comply
with Part M are also
available. Please refer to
page 6.
One cover
Pre-punched
Divider
Colour code suffix:
to indicate the finish you
require, add the required colour code to the
end of the product code.
Options:
optional colours and finishes are
available but these will be subject to minimum
quantity orders, longer lead times and set
up charges.
For more information contact the Technical
Team on 01424 856688.
Standard colour
WH
SG
WH:
White
SG:
Silver Grey
Note:
In order to sub-divide
Elegance 170, LP1005 dividing
fillets should be used
