GRP LADDER AND TRAY SYSTEMS
GRP ladder and tray systems
56 |
Standard span pressed tray
Product Information
All products are supplied in pack quantities of one.
A range of Pressed GRP Trays with 110mm wall height is
also available on request.
Complete range of Pultruded Trays for extended support
span up to 3 metres in 50mm and 80mm wall heights are
also available on request.
Please contact us on +44 (0)1424 856600 for a lead time.
p248
Technical
Information
Tray/trunking component chart
Base
Cover
–
–
KKST10050 KKSTD100
KKST15050 KKSTD150
KKST20050 KKSTD200
KKST30050 KKSTD300
KKST10080 KKSTD100
KKST15080 KKSTD150
KKST20080 KKSTD200
KKST30080 KKSTD300
KKST40080 KKSTD400
Flat tee (large radius)
Cover
Base
–
–
–
–
–
–
–
–
KKRL20080
200 to 100mm
KKRL30080
300 to 200mm
KKRL40080
400 to 300mm
–
–
–
–
–
–
KKRLD200
KKRLD300
KKRLD400
Reducer left hand
Base
Cover
–
–
–
–
–
–
–
–
–
–
–
–
–
–
KKRR20080
200 to 100mm KKRRD200
KKRR30080
300 to 200mm KKRRD300
KKRR40080
400 to 300mm KKRRD400
Reducer right hand
Pin rack
–
KR100
KR150
KR200
KR300
KR100
KR150
KR200
KR300
KR400
Base
Cover
KKSS5050 KKSSD50
KKSS10050 KKSSD100
KKSS15050 KKSSD150
KKSS20050 KKSSD200
KKSS30050 KKSSD300
KKSS10080 KKSSD100
KKSS15080 KKSSD150
KKSS20080 KKSSD200
KKSS30080 KKSSD300
–
–
Flat tee (small radius)
50 x 50mm tray
100 x 50mm tray
150 x 50mm tray
200 x 50mm tray
300 x 50mm tray
100 x 80mm tray
150 x 80mm tray
200 x 80mm tray
300 x 80mm tray
400 x 80mm tray
Length: 3 metres
Pack
1
