Round conduit accessory boxes

1 gang – square corners

code

depth pack

*MSSB10KWH

32mm 20

MSSB17KWH

44mm 10

Surface mounted

Flush mounted

2 gang – square corners

code

depth pack

*MSSB11KWH

32mm 10

MSSB23KWH

44mm 5

1 gang – radius corners

code

depth pack

MSSB19KWH

32mm 20

MSSB40KWH

44mm 10

2 gang – radius corners

code

depth pack

MSSB21KWH

32mm 10

MSSB41KWH

44mm 5

Cover plates

1 gang – flat

code

depth pack

MSCP2WH

2mm 20

Size: 86 x 86mm O/A

2 gang – flat

code

depth pack

MSCP3WH

2mm 10

Size: 86 x 146mm O/A

1 gang – raised

code

depth pack

MSSP10WH

9mm 10

Size: 85 x 85mm O/A

2 gang – raised

code

depth pack

MSSP20WH

9mm 2

Size: 85 x 145mm O/A

1 gang –

adjustable lug

code

depth pack

MSSB1WH

35mm 12

MSSB47WH

47mm 10

Entries: 2 x ø20mm on each of 3

sides (MSSB25)Entries: 2 x

ø20mm on each of 4 sides

(MSSB1 and MSSB47)

2 gang –

adjustable lug

code

depth pack

MSSB3WH

35mm 6

Entries : 4 x ø20mm on

horizontal sides, 2 x ø20mm on

vertical sides

Brass earthing terminal

code

rating pack

MET1

15Amp 100

*All standard surface boxes have 20mm KOs except MSSB10K and

MSSB11K which have 20mm pre-punched holes

Flush mounted 1 gang

cover – clip-on

code

depth pack

MSCP1WH

5.3mm 20

Size: 78 x 78mm O/A

Surface and flush mounted boxes

Surface mount boxes

1gang=87x87mmwith60.3fixingcentres

2gang=147x87mmwith120.6fixingcentres

Flushmountboxes

1gang=74x74mmwith60.3fixingcentres

2gang=134x74mmwith120.6fixingcentres
