Conduit systems
CONDUIT SYSTEMS
220 |
MT Supertube
Product information
•
20mm and 25mm
•
LSOH conduit
•
Excellent screening performance
•
Suitable for rail, marine and tunnel applications
•
ZERO WASTE: available in continuous lengths of up to 100 metres,
meaning fewer fittings per installation
•
Longer lengths also prevent ingress of water
•
Extra security
•
Suitable for in-screed applications
•
Withstands temperatures from – 40 º C to + 120 º C
•
Nail penetration: MT Supertube complies with requirements
for BS 7671, BS EN61386-1:2008
•
BS 8436 is specification for 300/500V screened electric cable
MT Supertube coils
code
size
pack
22010BK
20mm 1 x 100m
22505BK
25mm 1 x 50m
MT Supertube conduit
code
size
pack
22003WH
20mm 30 x 3m
22503WH
25mm 30 x 3m
Tube cutter
code
size
pack
20001
20-25mm 1
Tools
Coils and lengths
Stripping tool (pre-set)
code
size
pack
20002
20-25mm 1
Compact tube bender
code
size
pack
20003
20-25mm 1
Colour code suffix:
to indicate the finish
you require, add the required colour
code to the end of the product code.
Other colour options are available but
may be subject to longer lead times and
minimum order quantities. For further
information contact the Technical Team
on +44 (0)1424 856688.
FIRE SECURITY
MT Supertube FR Plus
MT Supertube is available to meet the requirements
of LUL (London Underground Ltd) engineering standard
2-01001-002:issue A1, material classification EQ/1
(equipment/limited and dispersed).
*
Please note MT Supertube FR Plus is not a standard stock item
and therefore lead times will apply.
MT Supertube is a unique, LSOH, 3-layer heavy
gauge conduit comprising polyethylene internal
and external layers over a continuous aluminium
tube that provides additional mechanical strength.
MT Supertube has excellent EMI screening
performance and is a practical and cost-saving
alternative to standard galvanised conduits.
Standard Colours
WH
BK
WH
: White
BK
: Black
MT Supertube FR
Plus coils
code
size
pack
220FR10BK*
20mm 1 x 100m
225FR05BK*
25mm 1 x 50m
MT Supertube FR
Plus conduit
code
size
pack
220FR03WH*
20mm 30 x 3m
225FR03WH*
25mm 30 x 3m
External Polyethylene layer
Aluminium layer
Internal Polyethylene layer
MT SUPERTUBE is a time saving alternative to
galvanised steel conduit. See page 223 for the
MT Supertube cost and labour saving comparison.
