Conduit systems
CONDUIT SYSTEMS
214 |
Round conduit and fittings
Light & heavygauge
Heavy gauge
code
O.D
pack
CR6WH
20mm 30 x 3m
CR7WH
25mm 30 x 3m
CR8WH
32mm 10 x 3m
CR11WH
38mm 10 x 3m
CR12WH
50mm 10 x 3m
For black replace the last two
letters of the code with BK
Round conduit fittings
Reducers
code
size
pack
MR2WH
25 x 20mm 50
Inspection elbows
code
size
pack
MIE2WH
20mm 20
For 25mm size use
Inspection Bend
Inspection tees
code
size
pack
MIT2WH
20mm 20
MIT3WH
25mm 20
Plain bends
code
size
pack
MNB2WH
20mm 25
MNB3WH
25mm 10
MNB4WH*
32mm 20
MNB5WH*
38mm 5
MNB6WH*
50mm 2
*Couplers required
Inspection bends
code
size
pack
MIB2WH
20mm 20
MIB3WH
25mm 20
Light gauge
code
O.D
pack
CR2WH
20mm 30 x 3m
CR3WH
25mm 30 x 3m
CR4WH
32mm 10 x 3m
CR9WH
38mm 10 x 3m
CR10WH
50mm 10 x 3m
For black replace the last two
letters of the code with BK
Straight couplers
code
size
pack
MC2WH
20mm 100
MC3WH
25mm 50
MC4WH
32mm 25
MC5WH
38mm 10
MC6WH
50mm 10
Plastic plugs – red only
(for heavy gauge conduit)
code
size
pack
MPP2
20mm 100
MPP3
25mm 100
MPP4
32mm 50
Light and heavy gauge options
Round conduit made from super high impact PVC-U.
Product information
CONDUIT
•
Light or heavy gauge options
•
Meet requirements for BS 4607, BS EN61386-1:2008,
BS EN 61386-21:2004+A11:2010 and BS EN 61386-25:2011
where applicable
BOXES
•
Provision for MET1 brass earth terminal
•
All boxes have threaded brass inserts
Expansion couplers
code
size
pack
MEC2WH
20mm 25
MEC3WH
25mm 10
MEC5WH
38mm 10
MEC6WH
50mm
5
Should be fitted over a clear
gap between two round rigid
conduits
Standard Colours
WH
BK
WH
: White
BK
: Black
See page 239 for Conduit Fire Clips
