PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
Twin Plus trunking | 153
Internal bend assembly
code pack
EIB60WH 1
External bend assembly
code pack
EXB60WH 1
External bend assembly
code pack
ESXB60WH 1
Capacity reduced by 50%
Note: 135° versions are also
available. For more information
call the Technical Team on
+44 (0)1424 856688
Twin Plus is a large, segregated,
two-compartment skirting and dado
trunking system that provides high
capacity cable containment for most
commercial environments.
Product information
• 210 x 57mm
• 2 large segregated compartments
• Can be subdivided
• Separate cover access to each compartment
• Suitable for skirting and dado application
Data information
• 50mm bend radius fttings
• Adjustable data box 32-47mm
• Screened divider and data boxes
Basic components
Fittings
Base unit
code pack
EMT60WH 2 x 3m
Cover
code pack
ETL1WH 8 x 3m
Coupler
code pack
EC60WH 1
End cap
code pack
EEC60WH 1
For additional retention use
end cap retaining screws G1310
(Pack 40)
PAGE
107
Two
separate
covers
Part M
For boxes that meet the
requirements of Part M
(DDA) please refer to
page 106 of this section.
Two large
segregated
compartments
Standard colour
WH
WH: White
antimicrobial trunking
‘Biooption’available
tospecialorder
p284
Technical
Information
