8 / 12
08
Data Trunking
from Marshall-Tufflex
3+ compartment trunking
System
Dimensions
Cable Capacity
based on typical values for Ø6.5mm, Ø7.0mm and Ø8.4mm data cables*
STERLING
PROFILE
4-13
PVC-U
ELEGANCE
170
ALUMINIUM
Profile 4 & 5:
218 x 50mm
Profile 6:
269 x 50mm
Profile
11, 12 & 13:
255 x 50mm
Comp 1 Comp 2 Comp 3 Comp 4
Profile 4
Ø6.5mm 18
-
54 19 52 17
-
Ø7.0mm 15
-
45 16 43 14
-
Ø8.4mm 10
-
31 11 30 10
-
Profile 5
Ø6.5mm 22
-
54 19 52 17
-
Ø7.0mm 18
-
45 16 43 14
-
Ø8.4mm 13
-
31 11 30 10
-
Profile 6
Ø6.5mm 52 17 54 19 52 17
-
Ø7.0mm 43 14 45 16 43 14
-
Ø8.4mm 30 10 31 11 30 10
-
Profile 11
Ø6.5mm 18
-
54 19 50 15
18
Ø7.0mm 15
-
45 16 42 13
15
Ø8.4mm 10
-
31 11 29 9
10
Profile 12
Ø6.5mm 18
-
54 19 50 15
20
Ø7.0mm 15
-
45 16 42 13
17
Ø8.4mm 10
-
31 11 29 9
12
Profile 13
Ø6.5mm 20
-
54 19 50 15
20
Ø7.0mm 17
-
45 16 42 13
17
Ø8.4mm 12
-
31 11 29 9
12
NO WITH
BOX
BOX
NO WITH
BOX
BOX
NO WITH
BOX
BOX
170 x 55
Comp 1 Comp 2 Comp 3
Elegance
170
Ø6.5mm
25
63 24
25
Ø7.0mm
21
53 20
21
Ø8.4mm
14
37
14
14
NO WITH
BOX
BOX
*All calculations allow for a 45% space factor
STERLING
XL
PVC-U &
ALUMINIUM
220 x 65mm
Comp 1 Comp 2 Comp 3
XL201
Ø6.5mm
39
67
35
39
Ø7.0mm
33
56
29
33
Ø8.4mm
23
39
20
23
NO WITH
BOX BOX
XL202
Ø6.5mm
39
67 35
49
Ø7.0mm
33
56 29
41
Ø8.4mm
23
39 20
29
XL203
Ø6.5mm
49
67 35
49
Ø7.0mm
41
56 29
41
Ø8.4mm
29
39 20
29
