ODYSSEY
PVC-U
06
Data Trunking
from Marshall-Tufflex
3+ compartment trunking
System
STERLING
PROFILE
1, 2 & 3
PVC-U
STERLING
PROFILE
3001, 3002
& 3003
ALUMINIUM
Dimensions
Cable Capacity
based on typical values for Ø6.5mm, Ø7.0mm and Ø8.4mm data cables*
167 x 50mm
167 x 50mm
Comp 1 Comp 2 Comp 3
Profile 1
Ø6.5mm 18
54
19
18
Ø7.0mm 15
45
16
15
Ø8.4mm 10
31
11
10
NO WITH
BOX BOX
Profile 2
Ø6.5mm 18
54
19
22
Ø7.0mm 15
45
16
18
Ø8.4mm 10
31
11
13
Profile 3
Ø6.5mm 22
54
19
22
Ø7.0mm 18
45
16
18
Ø8.4mm 13
31
11
13
Comp 1 Comp 2 Comp 3
3001
Ø6.5mm 15
53
21
16
Ø7.0mm 12
44
18
14
Ø8.4mm 9
31
12
9
NO WITH
BOX BOX
3002
Ø6.5mm 15
53
21
20
Ø7.0mm 12
44
18
16
Ø8.4mm 9
31
12
11
3003
Ø6.5mm 18
53
21
20
Ø7.0mm 15
44
18
16
Ø8.4mm 11
31
12
11
180 x 57mm
Comp 1 Comp 2 Comp 3
NO WITH
BOX BOX
Odyssey
Ø6.5mm 18
56
17
18
Ø7.0mm 15
47
14
15
Ø8.4mm 10
33
10
10
STERLING
CURVE
PROFILE
PVC-U
167 x 50mm
Comp 1 Comp 2 Comp 3
Profile 1
Ø6.5mm 16
54 19
16
Ø7.0mm 14
45 16
14
Ø8.4mm 10
31 11
10
NO WITH
BOX BOX
Profile 1
Ø6.5mm 16
54 19
22
Ø7.0mm 14
45 16
18
Ø8.4mm 10
31 11
13
*All calculations allow for a 45% space factor
