4 / 12
MAXI
PVC-U
04
Data Trunking
from Marshall-Tufflex
1 compartment trunking
2 compartment trunking
System
MINI
PVC-U
Dimensions
Cable Capacity
based on typical values for Ø6.5mm, Ø7.0mm and Ø8.4mm data cables*
*All calculations allow for a 45% space factor
TWIN165
PVC-U
COMPACT
1 & 2
PVC-U
TWIN PLUS
PVC-U &
ALUMINIUM
MTRS50:
50 x 50mm
MTRS75:
75 x 75mm
MTRS100:
100 x 100mm
Comp 1
With dividers
Comp 1 Comp 2 Comp 3
MTRS50
Ø6.5mm 28
13
13
-
Ø7.0mm 23
11 11
-
Ø8.4mm 16
7
7
-
MTRS75
Ø6.5mm 66
31
31
-
Ø7.0mm 55
26
26
-
Ø8.4mm 38
18
18
-
MTRS100
Ø6.5mm 122
33 20
57
Ø7.0mm 102
28
17
48
Ø8.4mm 71
19
12
33
MMT4:
38 x 25mm
Comp 1
MMT4
Ø6.5mm 10
Ø7.0mm 8
Ø8.4mm 6
210 x 57mm
Comp 1
Comp 2
Twin Plus
Ø6.5mm 66
34
66
34
Ø7.0mm 56
28
56
28
Ø8.4mm 39
20
39
20
NO BOX WITH BOX NO BOX WITH BOX
160 x 65mm
Comp 1
Comp 2
Twin165
Ø6.5mm 46
76
43
Ø7.0mm 38
63
36
Ø8.4mm 27
44
25
NO BOX
WITH BOX
Compact 1:
130 x 50mm
Compact 2:
130 x 50mm
Comp 1
Comp 2
Compact 1
Ø6.5mm 18
53
21
Ø7.0mm 15
44
17
Ø8.4mm 10
31
12
NO BOX
WITH BOX
Compact 2
Ø6.5mm 21
53
21
Ø7.0mm 18
44
17
Ø8.4mm 12
31
12
Compact 3:
181 x 50mm
Comp 1
Comp 2
Compact 3
Ø6.5mm 53
21
52
20
Ø7.0mm 44
18
43
17
Ø8.4mm 31
12
30
12
NO BOX WITH BOX NO BOX WITH BOX
COMPACT 3
PVC-U
