Klik 7 pin
Link Leads
Luminaire Leads
Link Leads
The link leads are used to
connect KLMB to KLMB all leads
are low smoke zero halogen
and are factory connected and
tested.
Note: to ensure correct
link lead selection see the
connection key on page 9.32
• 1.5mm
2
CSA
• 3m, 5m & 10m lengths
• Standard, Digital and
Emergency Luminaires
• 16A Rated
• BS 5733
• BS EN 61535
• Short circuit tested: 1500A
conditional rating
• Cable standard BS6500 &
BS7211
Supply Link Leads 16A Plug Out, Plug In 1.5mm
2
3 Core
Cat ref.
3m 3 Core Link Lead, Plug to Plug
KLA/3/1-5P
5m 3 Core Link Lead, Plug to Plug
KLA/5/1-5P
10m 3 Core Link Lead, Plug to Plug
KLA/10/1-5PX*
Supply Link Leads 16A Plug Out, Plug In 1.5mm
2
4 Core
Cat ref.
3m 4 Core Link Lead, Plug to Plug
KLG/3/1-5P
5m 4 Core Link Lead, Plug to Plug
KLG/5/1-5P
10m 4 Core Link Lead, Plug to Plug
KLG/10/1-5PX*
Supply Link Leads 16A Plug Out, Plug In 1.5mm
2
5 Core
Cat ref.
3m 5 Core Link Lead, Plug to Plug
KLK/3/1-5P
5m 5 Core Link Lead, Plug to Plug
KLK/5/1-5P
10m 5 Core Link Lead, Plug to Plug
KLK/10/1-5PX*
Supply Link Leads 16A Plug Out, Plug In 1.5mm
2
6 Core
Cat ref.
3m 6 Core Link Lead, Plug to Plug
KLV/3/1-5P
5m 6 Core Link Lead, Plug to Plug
KLV/5/1-5P
10m 6 Core Link Lead, Plug to Plug
KLV/10/1-5PX*
Supply Link Leads 16A Plug Out, Plug In 1.5mm
2
7 Core
Cat ref.
3m 7 Core Link Lead, Plug to Plug
KLZ/3/1-5P
5m 7 Core Link Lead, Plug to Plug
KLZ/5/1-5P
10m 7 Core Link Lead, Plug to Plug
KLZ/10/1-5PX*
* Special lengths are available to order (not stocked)
which includes 2.5mm
2
and 4mm
2
variants
Luminare Leads
Connections to the luminaire are
made via a pre-wired plug and
lead, all leads are low smoke
zero halogen and are factory
connected and tested
• Up to 5m lengths
• Standard, Digital and
Emergency Luminaires
• Short circuit tested: 1500A
conditional rating
• Cable standard BS6500 &
BS7211
Standard 6A Luminare Lead 0.75mm
2
3 Core
Cat ref.
1m 3 Core 0.75mm Luminaire Lead Plug to Wire
KLB/1/0-75W
2m 3 Core 0.75mm Luminaire Lead Plug to Wire
KLB/2/0-75W
3m 3 Core 0.75mm Luminaire Lead Plug to Wire
KLB/3/0-75W
4m 3 Core 0.75mm Luminaire Lead Plug to Wire
KLB/4/0-75W
5m 3 Core 0.75mm Luminaire Lead Plug to Wire
KLB/5/0-75W
Standard 10A Luminare Lead 1mm
2
3 Core
Cat ref.
1m 3 Core 1mm Luminaire Lead Plug to Wire
KLB/1/1W
2m 3 Core 1mm Luminaire Lead Plug to Wire
KLB/2/1W
3m 3 Core 1mm Luminaire Lead Plug to Wire
KLB/3/1W
4m 3 Core 1mm Luminaire Lead Plug to Wire
KLB/4/1W
5m 3 Core 1mm Luminaire Lead Plug to Wire
KLB/5/1W
Standard 16A Luminare Lead 1.5mm
2
3 Core
Cat ref.
1m 3 Core 1.5mm Luminaire Lead Plug to Wire
KLB/1/1-5W
2m 3 Core 1.5mm Luminaire Lead Plug to Wire
KLB/2/1-5W
3m 3 Core 1.5mm Luminaire Lead Plug to Wire
KLB/3/1-5W
4m 3 Core 1.5mm Luminaire Lead Plug to Wire
KLB/4/1-5W
5m 3 Core 1.5mm Luminaire Lead Plug to Wire
KLB/5/1-5W
