Klik 7 pin
Lighting Control Module
Lighting Control Module with KlikLink
Lighting Control Module Occupancy Sensors
The KLCM allows connection
and control of multiple luminaires
with four separate channels.
• Switching
• Dimming (DSI & DALI)
• Corridor hold
• Partition switching
• Daylight switching & dimming
• Scene settings
• Integral emergency test times
• Reset profiles
• Light level offset (channel to
channel)
See page 9.40-9.41 for more
information
Description
Cat Ref.
12 Way 4 Channel LCM Plug in, Plug out
KLCM412P
13 Way 4 Channel LCM Wire in, Plug out
KLCM413W
KlikLink iPad App
Klik LCM occupancy sensors
come complete with a 10m RJ11
lead and have integrated daylight
sensing.
Sensing options are selected via
the Kliklink app (e.g. presence/
absence)
KLCM-3OS is designed for use
as a corridor sensor.
KLCM-5OS is designed for use
as a whole room sensor.
LCM Occupancy Sensor with KlikLink
Cat ref.
Klik LCM Occupancy Sensor with KlikLink (provided with 10m RJ11 Lead)
KLCM-OS
LCM Wide Area Sensors
Cat ref.
Klik LCM Corridor Sensor with 3 Sensor Heads (Provided with RG11 lead)
KLCM-3OS
Klik LCM Wide Area Sensor with 5 Sensor Heads (Provided with RG11 lead)
KLCM-5OS
Lighting Control Module Switch Drop Lead SELV (Grey)
Lighting Control Module Link Lead SELV (Red)
RJ45 to switch (wire-in) lead
available in a variety of lengths
• SELV
• RJ45 connector
RJ45 to RJ45 link lead
• SELV
• RJ45 connector
(Cables supplied standard with RJ45 plug on both ends)
Description
Cat ref.
5m RJ45 SELV Switch Drop Lead
KLO5RJ45G
10m RJ45 SELV Switch Drop Lead
KLO10RJ45G
15m RJ45 SELV Switch Drop Lead
KLO15RJ45G
20m RJ45 SELV Switch Drop Lead
KLO20RJ45G
30m RJ45 SELV Switch Drop Lead
KLO30RJ45G
40m RJ45 SELV Switch Drop Lead
KLO40RJ45G
50m RJ45 SELV Switch Drop Lead
KLO50RJ45G
(Cables supplied standard with RJ45 plug on both ends)
Description
Cat ref.
5m RJ45 SELV Link Lead
KLO5RJ45R
10m RJ45 SELV Link Lead
KLO10RJ45R
15m RJ45 SELV Link Lead
KLO15RJ45R
20m RJ45 SELV Link Lead
KLO20RJ45R
30m RJ45 SELV Link Lead
KLO30RJ45R
40m RJ45 SELV Link Lead
KLO40RJ45R
50m RJ45 SELV Link Lead
KLO50RJ45R
RJ45 Splitter
KLORJ45CON
