SP&N distribution boards
SP&N distribution boards are
available from 4-28 outgoing
ways. The range comes with a
choice of either 100A 2P switch
disconnector, 63A 30mA 2P
RCCB or 100A 30mA 2P RCCB,
or a range of split load versions.
The range has the following
features:
• Ample wiring space, with
provision to accept RCBO’s
• Full complement of earth and
neutral terminal bars to accept
up to 25mm
2
incoming and
16mm
2
outgoing cable
• Accepts most consumer unit
accessories
• Suitable for cable entry/exit on
all sides and back
Construction
Manufactured from 0.9mm CR4
cold reduced mild steel,
phosphate pretreated and
powder coated to 00A01
BS 4800.
Complies with BS EN 61439-3.
DIN Rail Enclosures
One, two or three row 8-66
modules enclosures, fitted with
DIN rails to accept any
combination of Hager modular
devices from the simplest switch
and MCB arrangements to the
more sophisticated control and
protection system.
These enclosures feature:
• Ample wiring space
• Full complement of earth and
neutral bars fitted as standard
• Significant knockout provision
• Plain doors only
• Optional key lock
Complies with BS EN 62208.
For dimensions see page 3.5.
100A Switch Disconnector Incomer
Description
Cat ref.
4 Way 100A Switch Disconnector Incomer
JK104
6 Way 100A Switch Disconnector Incomer
JK106
10 Way 100A Switch Disconnector Incomer
JK110
14 Way 100A Switch Disconnector Incomer
JK114
20 Way 100A Switch Disconnector Incomer
JK120
28 Way 100A Switch Disconnector Incomer
JK128
63A 30mA RCCB Incomer
Description
Cat ref.
4 Way 63A 30mA RCCB Incomer
JK404H
6 Way 63A 30mA RCCB Incomer
JK406H
10 Way 63A 30mA RCCB Incomer
JK410H
14 Way 63A 30mA RCCB Incomer
JK414H
20 Way 63A 30mA RCCB Incomer
JK420H
100A 30mA RCCB Incomer
Description
Cat ref.
4 Way 100A 30mA RCCB Incomer
JK304H
6 Way 100A 30mA RCCB Incomer
JK306H
10 Way 100A 30mA RCCB Incomer
JK310H
14 Way 100A 30mA RCCB Incomer
JK314H
20 Way 100A 30mA RCCB Incomer
JK320H
28 Way 100A 30mA RCCB Incomer
JK328H
