1.11
Consumer Units
Skeleton Units
Consumer Units
Single Phase and Switched Neutral
Skeleton Units
Description
Cat ref.
Plain door
12 Way 100A Switch Incomer
VS112
10 Way Configurable
VS710C
100A Switch 1 x 63A 30mA RCCB
12 Way Configurable
VS712C
100A Switch 1 x 63A 30mA RCCB
10 Way 5+4+1
VS754U
100A Switch 2 x 63A 30mA RCCB
1 x Switch Fed Way for RCBO or MCB (to feed smoke detector for example)
10 Way 5+4+1
VS854U
100A Switch 2 x 80A 30mA RCCB
1 x Switch Fed Way for RCBO or MCB (to feed smoke detector for example)
Skeleton consumer units are
designed typically for use in
installations in areas with
pre-determined space available
e.g. Metering cupboards in Local
Authority accommodation.
Complies with BS EN 60439-3
and Annex ZA.
For complete accessories list
see page 1.13.
Single Phase and Switched Neutral Consumer Unit - Hybrid
These units take Single Pole and Switched Neutral single module MCBs.
Description
Enclosure
Cat ref.
size
Glazed door
8 Way Metal Single Phase and Switched Neutral
4
VH308NG
100A 30mA RCCB Incomer
Insulated and metal enclosures
1 row from 8 to 14 outgoing
ways.
Surface mounted enclosures,
with a rigid chassis, housing a
Switch Disconnector or RCCB
Incomer.
Supplied with marking labels,
SPSN busbar and instructions.
Options:
• Keylock
Complies with BS EN 60439-3.
For complete accessories list
see page 1.13.
For consumer unit dimensions
see page 1.15.
VS710C
Consumer
Units
