General Catalogue • Consumer Units
Consumer Units
Incomer with twin RCCB’s
100A Switch plus Twin RCCB - Insulated
Description
Enclosure
Cat ref.
Cat ref.
size
Plain door
Glazed door
6 Way 3+3
4
VC733H1
-
100A Switch 2 x 63A 30mA RCCB
10 Way 5+5
5
VC755H1
VC755H1G
100A Switch 2 x 63A 30mA RCCB
10 Way Configurable
5
VC710C1
VC710C1G
100A Switch 2 x 63A 30mA RCCB
12 Way 6+6
6
VC766H1
VC766H1G
100A Switch 2 x 63A 30mA RCCB
12 Way Configurable
6
VC712C1
VC712C1G
100A Switch 2 x 63A 30mA RCCB
14 Way Configurable
6
VC714C1
VC714C1G
100A Switch 2 x 63A 30mA RCCB
16 Way Configurable
6
VC716C1
VC716C1G
100A Switch 2 x 63A 30mA RCCB
10 Way 5+5
5
VC855H
-
100A Switch 2 x 80A 30mA RCCB
12 Way 6+6
6
VC866H
-
100A Switch 2 x 80A 30mA RCCB
16 Way Configurable
6
VC816C
-
100A Switch 2 x 80A 30mA RCCB
Insulated and metal, split load
and configurable enclosures, 1
row from 6-16 outgoing ways.
Surface and Flush mounted
enclosures, with a rigid chassis,
housing a Switch Disconnector
and 2 RCCB’s.
Supplied with marking labels,
busbar and instructions.
Options:
• Keylock
• Plain or glazed door
Complies with BS EN 60439-3
Annex ZA.
For complete accessories list
see page 1.13.
For insulated and hybrid
consumer unit dimensions see
page 1.15.
For flush consumer unit
dimensions see page 1.16.
100A Switch plus Twin RCCB - Hybrid
Description
Enclosure
Cat ref.
size
Plain door
10 Way 5+5
5
VH755H1
100A Switch 2 x 63A 30mA RCCB
12 Way 6+6
6
VH766H1
100A Switch 2 x 63A 30mA RCCB
12 Way Configurable
6
VH712C1
100A Switch
2 x 63A 30mA RCCB
14 Way Configurable
6
VH714C1
100A Switch 2 x 63A 30mA RCCB
10 Way 5+5
5
VH855H
100A Switch 2 x 80A 30mA RCCB
12 Way 6+6
6
VH866H
100A Switch 2 x 80A 30mA RCCB
100A Switch plus Twin RCCB - Flush
Description
Enclosure
Cat ref.
size
Plain door
10 Way Configurable
5
VF710C1
100A Switch 2 x 63A 30mA RCCB
12 Way Configurable
6
VF712C1
100A Switch 2 x 63A 30mA RCCB
14 Way Configurable
6
VF714C1
100A Switch 2 x 63A 30mA RCCB
16 Way Configurable
6
VF716C1
100A Switch 2 x 63A 30mA RCCB
12 Way Configurable
6
VF812C
100A Switch 2 x 80A 30mA RCCB
14 Way Configurable
6
VF814C
100A Switch 2 x 80A 30mA RCCB
VC816C
VF710C1
