1.7
Consumer Units
Incomer with twin RCCB’s with Unprotected Ways
100A Switch plus Twin RCCB with Unprotected Ways - Insulated
Description
Enclosure
Cat ref.
Cat ref.
size
Plain door
Glazed door
10 Way Configurable
5
VC710CU
VC710CUG
100A Switch 2 x 63A 30mA RCCB
16 Way Configurable
6
VC716CU
VC716CUG
100A Switch 2 x 63A 30mA RCCB
10 Way 3+4+3
5
VC7343U
-
100A Switch 2 x 63A 30mA RCCB 3 x MCB
14 Way 5+6+3
6
VC7563U
-
100A Switch 2 x 63A 30mA RCCB 3 x MCB
16 Way Configurable
6
VC816CU
-
100A Switch 2 x 80A 30mA RCCB
18 Way Configurable
6
VC818CU
VC818CUG
100A Switch 2 x 80A 30mA RCCB
10 Way 5+4+1
5
VC854U
-
100A Switch 2 x 80A 30mA RCCB 1 x MCB
14 Way 5+6+3
6
VC8563U
-
100A Switch 2 x 80A 30mA RCCB 3 x MCB
14 Way 7+6+1
6
VC876U
-
100A Switch 2 x 80A 30mA RCCB 1 x MCB
Insulated and metal enclosures,
1 row from 10 to 18 outgoing
ways.
Surface and Flush mounted
enclosures, with a rigid chassis,
housing a Switch
Disconnector, Twin RCCB and
space for RCBOs.
Supplied with marking labels,
configurable busbar and
instructions.
Options:
• Keylock
• Plain or glazed door
Complies with BS EN 60439-3
Annex ZA.
For complete accessories list
see page 1.13.
For insulated and hybrid
consumer unit dimensions see
page 1.15.
For flush consumer unit
dimensions see page 1.16.
100A Switch plus Twin RCCB with Unprotected Ways - Hyrbid
Description
Enclosure
Cat ref.
Cat ref.
size
Plain door
Glazed door
16 Way Configurable
6
VH716CU
-
100A Switch 2 x 63A 30mA RCCB
10 Way 3+4+3
5
VH7343U
-
100A Switch 2 x 63A RCCB 3 x MCB
16 Way Configurable
6
VH816CU
-
100A Switch 2 x 80A 30mA RCCB
10 Way 3+4+3
5
-
VH8343UG
100A Switch 2 x 80A RCCB 3 x MCB
10 Way 5+4+1
5
VH854U
-
100A Switch 2 x 80A RCCB 1 x MCB
14 Way 7+6+1
6
VH876U
-
100A Switch 2 x 80A RCCB 1 x MCB
100A Switch plus Twin RCCB with Unprotected Ways - Flush
Description
Enclosure
Cat ref.
size
Plain door
16 Way Configurable
6
VF716CU
100A Switch 2 x 63A 30mA RCCB
16 Way Configurable
6
VF816CU
100A Switch 2 x 80A 30mA RCCB
VC816CU
VH716CU
Consumer
Units
