General Catalogue • Technical • tebis.KNX
Room Controller
ambient
controller
Central screen
Sensory keys
➀
➁
➂
Technical Specification
TX450A
TX450B
Colour
White
Silver
Supply
30V DC bus EIB TX111
Consumption
150mW
Assembly
Surface mounting
Accessories included
BCU
Configuration
With TX100GB or with ETS software and
the application: TL450A
Working Temperature
0ºC to +45ºC
Size
80 x 80mm
Function
The room controller is a control and display wall appliance for the
tebis system.
Available in 2 colours (white or silver)
It combines several functions in a single product
Through its 4 sensory keys, it allows :
• The control of lighting, roller shutters, heating etc.
• The control of functions developed as scenarios
The central screen:
• Display of information on the state of equipment
• Display of the hour , date, ambient temperature...
This different information is parametered through the
“Adjustments”
and
“Configuration”
mode included in the product.
Electrial Connection
• Connect the BCU
➁
to EIB bus by EIB connector
• Screw the assembly plate with BCU on anchoring box
➀
• Clip the front face
➂
to the BCU.
