General Catalogue • Technical • tebis.KNX
Control Types
Symbol and Function
Applications Symbols Control Type
Control Product
Lighting
Switching on only
Automatic contact or push button, or TX512, TXA023, TX025
Switching off only
Automatic contact or push button, or TX512, TXA023, TX025
Switch type ON/OFF
Automatic contact or push button, or TX512, TXA023, TX025
Remote break type ON/OFF
Push button
Remote break type ON/OFF for
unidirectional products
RF Push button
Increase the dimming level
Push button
Decrease the dimming level
Push button
Dimming on push button
Push button or detector, TX511, TXA023
Priority setting STOP
Automatic switch or contact, or TX510, TXA023, TX025
Priority setting START
Automatic switch or contact, or TX510, TXA023, TX025
Timed start - delay before ON
Automatic switch or contact, or TX510, TXA023, TX025
Timed stop - delay before OFF
Automatic switch or contact, or TX510, TXA023, TX025
Lighting level 25%, 50%, 75% or 100% TX510, TXA023, Tx025
Blinds/
Roller Shutters
Push button type UP
Push button
Push button type DOWN
Push button
Push button type UP-DOWN
Push button
Switch type UP-DOWN function
Automatic switch or contact, or TX510, TXA023, TX025
Swtich type UP function
Automatic switch or contact, or TX510, TXA023, TX025
Switch type DOWN function
Automatic switch or contact, or TX510, TXA023, TX025
Override UP
Automatic switch or contact, or TX510, TXA023, TX025
Override DOWN
Automatic switch or contact, or TX510, TXA023, TX025
Wind safety
TG050 air safety detector
Heating
Comfort
Temp. regulator, TX510 automatic push button or contact
Eco
Temp. regulator, TX510 automatic push button or contact
Comfort / Eco
Temp. regulator, TX510, TXA023 automatic contact
Frost free or without frost
Temp. regulator or automatic contact TX510, TXA023
Stop override
Automatic switch or contact or TXA023
Comfort override
Automatic switch or contact or TXA023, TX510
Eco override
Automatic switch or contact or TXA023, TX510
Timed comfort
Push button or detector TX510-TX511
Timed eco
Push button
TXA023
Clocks
Master clock
Diffusion TXA023 of the hour on the bus for synchronizing the slave
clocks
Slave clock
TXA023 synchronization on the hour emitted by the master
clock
TX025
Photo electric
switch
Master photocell switch
TX025 light sensitive switch (master) spreads on the bus the light
intensity measured by the cell
Slave photocell switch
TX025 light sensitive switch reads the light intensity measured by
the cell and broadcasted by the master light sensitive switch
TX450A
TX450B
Ambient
controllers
Display zone on the room controller
(1 to 4)
Each zone (1 to 4) can display information (temperature hours,
date) as well as states or measurements (lighting, heating, physical
measurements or functions)
Logical function
Creation of logical functions for displaying information on the
system
All Applications
?
No function
Scenario 1 to 8
Push button
