MK Electric Catalogue No. 49

62 / 759

K4204 1
4 GANG 6A
4 PIN SOCKET
LIGHTING DISTRIBUTION BOX
K4206 1
6 GANG 6A
4 PIN SOCKET
LIGHTING DISTRIBUTION BOX
DIMENSIONS
K4204: 80 x 222 x 237mm
K4206: 80 x 222 x 290mm
K4208: 80 x 222 x 400mm
K4210: 80 x 222 x 465mm
MOUNTINGS
Provision for screw (No. 8) fix to walls
or trunking and slots for *Caddy Clips
on top, bottom and back faces.
Conduit entries with snap fit blanks;
20 & 25mm in top, bottom and back
faces. Outlets can be wired as 1 or
2 banks.
TERMINAL CAPACITY
3 x 6mm rated at 16A.
Each socket is rated at 6A.
Extruded aluminium body with VO
rated plastic terminal housing. Both
3 & 4 pin plugs can be used with the
distribution box 4 pin socket outlets.
BS 5733
K4208 1
8 GANG 6A
4 PIN SOCKET
LIGHTING DISTRIBUTION BOX
K4210 1
10 GANG 6A
4 PIN SOCKET
LIGHTING DISTRIBUTION BOX
*Caddy Clip is a registered trade mark of
Erico Europa (UK) Ltd. Reading.
Distribution
Boxes
Fixing of the distribution box to lighting trunking is
made easy through the choice of cable entry points.
The distribution box can be suspended on drop rods
utilising Caddy Clips.*
The distribution box can be fitted directly to the wall or
ceiling using the pilot holes provided in the base.
K4208
K4210
K4204
K4206
62
WIRING DEVICESWHITE
