STRAIGHT
PANEL MOUNTING
IP44
SPLASHPROOF
200 - 250V
50 - 60 HZ
SURFACE – LOOP IN
SURFACE-LOOP IN
Amps
Pin.
Config-
uration Earth
16 2P+E 6 K9001BLU K9101BLU K9201BLU K13301BLU K9401BLU
16 3P+E 9 K9006BLU K9106BLU K9206BLU
16 3P+N+E 9 K9014BLU K9114BLU K9214BLU
32 2P+E 6 K9033BLU K9133BLU K9233BLU K13333BLU K9433BLU
32 3P+E 9 K9036BLU K9136BLU K9236BLU
32 3P+N+E 9 K9044BLU K9143BLU K9240BLU
63 2P+E 6 K9063BLU K9172BLU K9274BLU K9472BLU
16A/32A
Fitted with cable entry gland.
63A
Fitted with cable entry gland
BS EN 60309
16A/32A
Fitted with cable entry gland.
63A
Fitted with cable entry gland
BS EN 60309
16A Top conduit (M20) or rear
cable entry, complete with
blanking plug.
32A Top conduit (M25) or rear
cable entry, complete with
blanking plug.
63A Top conduit (M32) or rear
cable entry, complete with
blanking plug
BS EN 60309
Suitable for top entry 1 x M20
and 1 x M25 or bottom entry
1 x M20 and 1 x M25
BS EN 60309
16/32A
All flanges have the same
fixing centres and outside
dimensions to assist panel
builders
BS EN 60309
Plugs Connectors Socket Outlets
ANGLED
SURFACE
Connectors Socket Outlets
ANGLED
SURFACE
Plugs
Amps
Pin.
Config-
uration Earth
16 2P+E 6 K9024BLU K9124BLU K9194BLU K13024BLU
16 3P+E 6 K9081BLU K9082BLU K9083BLU
32 2P+E 6 K9054BLU K9156BLU K9762BLU K13054BLU
32 3P+E 6
63 2P+E 6 K9298BLU K9856BLU K9857BLU
Suitable for flexible cable only
63A. With external clamp
BS EN 60309
Suitable for flexible cable only
63A. With external clamp
BS EN 60309
Suitable for top entry 2 x M25
or bottom entry 2 x M20.
Will accept FL13 flange at top
BS EN 60309
Suitable for top entry 1 x M20
and 1 x M25 or bottom entry
1 x M20 and 1 x M25
BS EN 60309
Photographs feature the most representative products.
Design changes may occur (over different current ratings)
from one product to another.
258
WIRING DEVICES
INGRESS PROTECTED
Commando
