MK Electric Catalogue No. 49

256 / 759

Amps
Pin.
Config-
uration Earth
16 2P+E 4 K9000YEL K9100YEL K9200YEL K9400YEL K13300YEL
32 2P+E 4 K9032YEL K9132YEL K9232YEL K9432YEL K13232YEL
Fitted with cable entry seal.
BS EN 60309
Fitted with cable entry seal.
BS EN 60309
16A
Top conduit (M20) or rear
cable entry, complete with
blanking plug.
32A
Top conduit (M25) or rear
cable entry, complete with
blanking plug.
BS EN 60309
All flanges have the same
fixing centres and outside
dimensions to assist panel
builders.
BS EN 60309
Suitable for top entry 1 x M20
and 1 x M25 or bottom entry
1 x M20 and 1 x M25
BS EN 6030
PANEL MOUNTING
IP44
SPLASHPROOF
100-130V
50-60 HZ
IP67
WATERTIGHT
100-130V
50-60 HZ
Plugs Connectors
Connectors
Socket Outlets
Socket Outlets
STRAIGHT
PANEL MOUNTING SURFACE – LOOP IN
SURFACE – LOOP IN
ANGLED
SURFACE
ANGLED
SURFACE
Plugs
Amps
Pin.
Config-
uration Earth
16 2P+E 4 K9023YEL K9123YEL K9193YEL K9802YEL K13323YEL
32 2P+E 4 K9053YEL K9155YEL K9761YEL K13303YEL
Suitable for flexible cable only.
BS EN 60309
Suitable for flexible cable only.
BS EN 60309
16A Top conduit (M20) or rear
cable entry, complete with
blanking plug.
32A Top conduit (M25) or rear
cable entry, complete with
blanking plug
BS EN 60309
All flanges have the same
fixing centres and outside
dimensions to assist panel
builders
BS EN 60309
Suitable for top entry 1 x M20
and 1 x M25 or bottom entry
1 x M20 and 1 x M25
BS EN 60309
