MK Electric Catalogue No. 49

248 / 759

MK9933 1
M20 EARTH LEAD
ADAPTOR FOR EARTHING
METAL CONDUIT
56890GRN 5
REPLACEMENT
NEON LOCATOR
K56506GRY 1
K56506WHI 1
K56506BLK 1
JUNCTION BOX
WITH FOUR
4-WAY TERMINALS
Fixing holes are for No. 8
woodscrews (not supplied).
The enclosure has 4 entries, 1
on top, bottom and both sides.
TERMINAL CAPACITY
Each terminal block accepts
four 2.5mm 2 cables.
DIMENSIONS
95 x 95 x 65mm
BS 6220:1983
IP66 to BS EN 60529
K56500GRY 1
K56500WHI 1
1 GANG
PLASTER/TILE FLUSH
MOUNTING FRAME WITH
PROTECTIVE COVER
FOR USE WITH
160 X 117MM PRODUCTS
56500GRY 1
56500WHI 1
1 GANG
PLASTER/TILE FLUSH
MOUNTING FRAME WITH
PROTECTIVE COVER
FOR USE WITH
95 X 95MM SWITCHES
K56501GRY 1
K56501WHI 1
2 GANG
PLASTER/TILE FLUSH
MOUNTING FRAME WITH
PROTECTIVE COVER
The Flush adaptors for plaster
and tile can be used with finish
depths up to 20mm, by using
the spacers provided.Allows
flush mounted Masterseal
Plus™ products to maintain
their IP rating.
Can be used with side entry or
back entry enclosures.
DIMENSIONS
56500 115 x 115 x 34mm
K56500 135 x 135 x 34mm
K56501 135 x 195 x 34mm
K56502GRY 1
K56502WHI 1
1 GANG
FLUSH MOUNTING
BEZEL FOR USE WITH
160 X 117MM PRODUCTS
56502GRY 1
56502WHI 1
1 GANG
FLUSH MOUNTING
BEZEL FOR USE WITH
95 X 95MM SWITCHES
K56503GRY 1
K56503WHI 1
2 GANG
FLUSH MOUNTING BEZEL
The Flush adaptors for brick
and cavity walls should be
used on vertical surfaces
where no additional finishing,
such as plastering is required.
Allows flush mounted
Masterseal Plus™ products to
maintain their IP rating.
Can only be used with back
entry enclosures.
Supplied with 4 self tapping
screws to fix enclosure to
mounting bezel.
Clip-on surround hides
mounting screws.
DIMENSIONS
56502 145 x 145 x 41mm
K56502 165 x 165 x 41mm
K56503 165 x 245 x 41mm
56460GRY 5
56460WHI 5
ENTRY BLANK
56461BLK 5
56461WHI 5
PVC CABLE ENTRY
TO PROVIDE DIRECT
ENTRY OF POWER CABLE
TO THE UNIT VIA THE
BOTTOM BOX ENTRY
56462BLK 5
56462WHI 5
20MM PLAIN CONDUIT
ENTRY PUSH FIT
ADAPTOR BETWEEN
BACK BOX AND 20MM
PLAIN CONDUIT
56463BLK 5
56463WHI 5
20MM THREADED
CONDUIT ENTRY PUSH
FIT ADAPTOR BETWEEN
BACK BOX AND 20MM
THREADED CONDUIT
56464BLK 5
56464WHI 5
BOX COUPLER
FOR GANGING ONE
MASTERSEAL PLUS ™
BOX NEXT TO ANOTHER
K5844WHI 5
RJ45 CAT 5e
ANGLED UNSCREENED
ONE MODULE
K5887WHI 5
K5887BLK 5
RJ11/12
ONE MODULE
K5844
Enhanced Cat 5e performance.
Suitable for both 568A and
568B wiring schemes.
ISO/IEC 11801
EN 50173
TIA 568
EN 41003
K5887
Suitable for both RJ11 and
RJ12 jacks
RJ11 4 wire
RJ12 6 wire
FCC68
EN 41003
DIMENSIONS
25 x 50mm
Accessories
56890GRN
MK9933
DATA
K5844WHI
K5887WHI
Junction
Boxes
30 AMP
IP66
K56506GRY
K56506WHI
(COVER OFF)
Flush
Mounting
Frames
Flush
Mounting
Bezels
Conduit
Entries
K56502GRY K56500GRY
56500WHI 56502WHI
56461WHI
56462WHI
56463WHI
56464WHI
56460WHI
K56506WHI
(COVER ON)
K56501GRY K56503GRY
K5887BLK
Euro Data
Modules
See Logic Plus
page 46-48 for a
full range of
Euro modules
248
WIRING DEVICES
Masterseal Plus™
INGRESS PROTECTED IP66
