OPERATING MODES
Function
Description
Push button dimmer
with memory
Non cyclic dimming with maximum & minimum brightness limit adjustment.
Soft start switch on at last dimming level.
Push button dimmer
without memory
Non cyclic dimming with maximum & minimum brightness limit adjustment.
Soft start switch on at maximum level.
Push button cyclic dimmer
with memory
Cyclic dimming with maximum & minimum brightness limit adjustment.
Soft start switch on at last dimming level.
Push button cyclic dimmer
without memory
Cyclic dimming with maximum & minimum brightness limit adjustment.
Soft start switch on at maximum level.
Stairwell lighting controller
with turn off warning
Time Delay Switch with 50% brightness turn off warning. Adjustable time-on period between 1sec – 2.3hrs.
Adjustable turn-off warning periods between 1sec – 8min.
Stairwell lighting controller
without turn of warning
Time Delay Switch without turn off warning. Adjustable brightness and time-on period.
Scene Control Dimmer
Two user adjustable preset scene levels.
Rotary Dimmer
using 0/1-10V control
Rotary control dimming with conventional 0/1-10V controls, (e.g. MK K4499).
PRODUCT SELECTOR
List Number
Description
230V Tungsten
Filament Lamps
12V Wirewound
Transformers
12V Electronic
Transformers
K1400
1kW Universal Dimmer
– Master/Slave
Yes
60-1000W
Yes
50-900VA
Yes
50-900VA
K1401M
1kW Leading Edge Dimmer
– Master
Yes
60-1000W
Yes
50-900VA
–
K1401S
1kW Leading Edge Dimmer
– Slave
Yes
60-1000W
Yes
50-900VA
–
K1402M
1kW Trailing Edge Dimmer
– Master
Yes
60-1000W
–
Yes
50-900VA
K1402S
1kW Trailing Edge Dimmer
– Slave
Yes
60-1000W
–
Yes
50-900VA
COMPATIBLE WIRING DEVICES
List Number
Descripton
Product Range
K4499WHI / BLK
0-10V Fluorescent Controller One Module
Grid Plus
K4900WHI / BLK
10A Retractive Grid Switch
Grid Plus
