BETA Protecting
Miniature Circuit Breakers
Configuration
1/72 Siemens ET B1 · 10/2008
1
* You can order this quantity or a multiple thereof.
Selectivity for miniature circuit breakers/circuit breakers
In the event of a short-circuit, there is selectivity between miniature
circuit breakers and motor starter protectors according to
IEC/EN 60947-2 or DIN VDE 0660-101 up to the specified values
in kA.
Limit values of selectivity for miniature circuit breakers/fuses in kA
1) In 240/415 V, 50 Hz systems, the selectivity limits are reduced by 10 %.
I > r tripping current.
Downstream miniature circuit breakers Upstream circuit breakers
3RV1.3
In [A] 16 20 25 32 40 45 50
I >[A] 192 240 300 384 480 540 600
Icn [kA] 50 50 50 50 50 50 50
Selectivity limits [kA]1)
5SY4 ...-5
Characteristic A 2 6 10 0.2 0.8 1.2 2.5 3 6 6
10 30 10 0.2 0.4 0.5 0.6 0.8 1 1.2
16 48 10 -- 0.3 0.4 0.6 0.8 0.8 1
32 96 10 -- -- -- -- 0.6 0.8 0.8
40 120 10 -- -- -- -- -- -- 0.8
5SY4, 5SY7...-6
Characteristic B 6 30 6/10/15 0.2 0.3 0.5 0.6 0.8 1 1.2
10 50 6/10/15 0.2 0.3 0.4 0.6 0.8 1 1.2
13 65 6/10/15 0.2 0.3 0.4 0.6 0.8 1 1
16 80 6/10/15 -- 0.3 0.4 0.6 0.8 1 1
20 100 6/10/15 -- -- 0.4 0.6 0.8 1 1
25 125 6/10/15 -- -- -- 0.5 0.6 0.8 0.8
32 160 6/10/15 -- -- -- -- 0.6 0.8 0.8
40 200 6/10/15 -- -- -- -- -- -- 0.8
50 250 6/10/15 -- -- -- -- -- -- --
5SY6, 5SY4, 5SY7...-7
Characteristic C 0.5 5 6/10/15 0.3 0.5 0.6 1 1 1.5 3
1 10 6/10/15 0.3 0.5 0.6 1 1 1.5 3
1.6 16 6/10/15 0.3 0.5 0.6 1 1 1.5 3
2 20 6/10/15 0.3 0.5 0.6 1 1 1.5 3
3 30 6/10/15 0.2 0.3 0.4 0.6 0.8 1 1
4 40 6/10/15 0.2 0.3 0.4 0.6 0.8 1 1
6 60 6/10/15 0.2 0.3 0.4 0.6 0.8 1 1
8 80 6/10/15 0.2 0.2 0.4 0.6 0.6 0.8 1
10 100 6/10/15 0.2 0.2 0.4 0.6 0.6 0.8 1
13 130 6/10/15 0.2 0.2 0.4 0.6 0.6 0.8 1
16 160 6/10/15 -- 0.2 0.4 0.6 0.6 0.8 1
20 200 6/10/15 -- -- 0.4 0.6 0.6 0.8 1
25 250 6/10/15 -- -- -- 0.5 0.6 0.8 0.8
32 320 6/10/15 -- -- -- -- 0.6 0.8 0.8
40 400 6/10/15 -- -- -- -- -- -- 0.8
50 500 6/10/15 -- -- -- -- -- -- --
63 630 6/10/15 -- -- -- -- -- -- --
5SY6, 5SY4, 5SY7...-8
Characteristic D 2 40 6/10/15 0.3 0.5 0.6 0.8 1.2 1.5 1.5
6 120 6/10/15 0.2 0.3 0.4 0.6 0.8 1 1
10 200 6/10/15 -- 0.3 0.4 0.5 0.6 0.8 0.8
16 320 6/10/15 -- -- -- 0.5 0.6 0.6 0.8
32 640 6/10/15 -- -- -- -- -- 0.6 0.6
40 800 6/10/15 -- -- -- -- -- -- --
50 1000 6/10/15 -- -- -- -- -- -- --
