BETA Switching

Timers

7

LF4 digital time switches

9/4

Siemens ET B1 · 10/2008

9

Technical specifications

1)

For 24 V devices (7LF4 421-2, 7LF4 422-2 and 7LF4 444-2):

Tolerance -10/+10 %; operating range 0.9 ... 1.1 x U

c

.

2)

For 24 V devices (7LF4 421-2, 7LF4 422-2 and 7LF4 444-2):

Frequency range 0 ... 60 Hz.

3)

For 24 V device (7LF4 444-2): P

v

= 4 VA.

4)

At 25 °C a clock error of +0.3 s is assumed. Accuracy may deviate by a

further ± 1 s around this value.

5)

A program consists of an ON time, an OFF time and assigned ON and OFF

days or day blocks.

Mini

Top

Profi

Astro

Expert

7

LF4 401-5

7

LF4 411

7

LF4 412

7

LF4 421

7

LF4 422

7

LF4 431

7

LF4 432

7

LF4 444

Standards

EN 60730-1, -2-7; VDE 0631-1, -2-7; UL 60730

Approved acc. to

VDE, UL 60730-1,-2-7/UL 917 CSA C22.2 No. 14 and 177

Supply

Rated control supply voltage U

c

V AC

V AC/DC

110 ... 240

--

120, 230

--

120, 230

24

230

--

120/230

24

-

Operating range

×U

c

0.85 ... 1.1

0.85 ... 1.1

0.85 ... 1.1

1)

0.85 ... 1.1

80 .. 253

V

1)

-

Frequency ranges

Hz

50 ... 60

50 ... 60

50 ... 60

2)

50 ... 60

50 ... 60

2)

Rated power dissipation P

v

VA 0.035

2

2

2

2.5/4

3)

Channels/contacts

Switching channels

1

1

or 2

4

-

Rated operational voltage U

e

V AC 250

-

Rated operational current

I

e

At p.f. = 1

A

16

At p.f. = 0.6

A

10

Contacts

1

CO

1

or 2 CO

4

CO

-

Mechanical switching cycles (in millions)

> 5

10

-

Electrical switching cycles

At p.f. = 1

6000 (20

A)

100 000

Minimum contact load

V; mA 12; 100

-

Incandescent lamp load

A

5

8

-

Fluorescent lamp load

At 7 F

VA 58

60

Uncorrected

VA 1400

Safety

Different phases permissible between drive/contact

Yes

Rated impulse withstand voltage U

imp

kV

4

-

EMC: burst

Acc. to IEC 61000-4-4 kV

> 4.4

-

EMC: surge

Acc. to IEC 61000-4-5 kV

> 2.0

-

Electrostatic discharge

Acc. to IEC 61000-4-2 kV

> 8.0

Power reserve storage

Mains/battery

a

6/2

6

5

-

Battery type

Li primary cell

Program memory

Non-volatile

--

Yes

Overvoltage category

Acc. to EN 61010-1

III

Function

Minimum switching sequences

1

min

1

s

Make and break cycles

1

min

1

s

Clock errors per day

Typical

s/day

+0.3

±

1

4)

±

0.86

±

0.2

Control input

Terminal S

--

Yes

Memory spaces

-

Programs

5)

28

56 (2

× 28)

28 (2

× 14)

4

× 3 × 28

-

Pulse (alternatively)

--

84

--

-

Pulse cycle

--

1

s ... < 60 min --

Terminals

Terminals ± screw (Pozidriv)

PZ 1

Conductor cross-sections of main current paths

-

Rigid, max.

mm

2

4

-

Rigid, min.

mm

2

1.5

-

Flexible with end sleeve

Max.

mm

2

2.5

Environmental conditions

Permissible ambient temperature

°C -10 ... +55

-20 ...

+55

Storage temperature

°C -20 ... +60

Resistance to climate

Acc. to EN 60068-1

10/055/21

20/055/21

Degree of protection

Acc. to EN 60529

IP20, with connected conductors

Safety class

Acc. to EN 60730-1

II

© Siemens AG 2008
