BETA Switching

Switching Devices

5

TT5 7 Insta contactors, DC technology

8/15

Siemens ET B1 · 10/2008

8

*

You can order this quantity or a multiple thereof.

Technical specifications

5

TT5 73

5

TT5 74

5

TT5 75

4-

pole

4-

pole

4-

pole

Standards

EN 60947-4-1; EN 60947-5-1; EN 61095; UL 508

Approved acc. to

UL 508; UL File No. E303328

Rated frequency at AC f

n

Hz

40 ... 450

Rated control voltage U

c

V AC

24, 115, 230

24, 230

V DC

24, 110, 220

24, 220

Operating range

×

U

c

0.85 ... 1.1

Rated operational voltage U

e

V

440

Rated operational current

I

e

At V AC

Acc. to UL 480; acc. to IEC 440

AC-1/AC-7a, NO contacts

A

24

40

63

AC-1/AC-7a, NC contacts

A

24

30

30

AC-3/AC-7b, NO contacts

A

9

22

30

AC-3/AC-7b, NC contacts

A

6

--

--

Rated power dissipation P

v

Pick-up power

VA/W

4/4

5/5

65/65

Holding power

VA/W

4/4

5/5

4.2/4.2

Per contact AC-1/AC-7a

VA

1.5

3

6

Switching times

Closing (NO contacts)

ms

40

Opening (NO contacts)

ms

40

Rated impulse withstand voltage U

imp

kV

4

Contact gap

(

NO contacts) min.

mm

2.4

2.8

2.6

Electrical service life

At

I

e

and load

AC-1/AC-7a

For switching

cycles

150000

AC-3/AC-7b

For switching

cycles

500000

170000

240000

Mechanical service life

For switching

cycles

1

million

Maximum switching frequency

At load

AC-1/AC-7a

Switching

cycles/h

300

AC-3/AC-7b

Switching

cycles/h

600

Switching of resistive loads AC-1

V AC

230

For rated operational power P

s

(

NO contacts)

Single-phase

kW

5.3

8.8

13.8

Three-phase

kW

16

26

41

Switching of three-phase asynchronous motors AC-3

V AC

400

For rated operational power P

s

(

NO contacts)

Single-phase

kW

--

Three-phase

kW

4

11

15

Minimum switching capacity

V; mA

17; 200

Overload withstand capability

Per conducting path (NO contacts only)

At 10 s

A

72

176

240

Short-circuit protection, according to coordination type 1

Back-up fuse characteristic gL/gG

A

35

63

80

Terminals

±

screw (Pozidriv)

Coil connection

1

1

1

Main connection

1

2

2

Tightening torques

Coil connection

Nm

0.9

0.9

0.9

Main connection

Nm

1.0

2.5

2.5

Conductor cross-sections

Coil connection

-

Solid

mm

2

1.5 ... 4

-

Stranded, with end sleeve

mm

2

1.5 ... 2.5

-

AWG cables

AWG

16 ... 10

Tightening torques

lb. in

8

Main connection

-

Solid

mm

2

1.5 ... 10

2.5 ... 25

-

Stranded, with end sleeve

mm

2

1.5 ... 2.5

2.5 ... 16

-

AWG cables

AWG

16 ... 8

16 ... 4

Tightening torques

lb. in

9

20

Permissible ambient temperature

For operation

°C

-25 ...

+55

For storage

°C

-50 ...

+80

Degree of protection

Acc. to EN 60529

IP20, with connected conductors

Acc. to UL 508

I

n

A

24

40

63

UL 508 General Use 240 V/480 V

FLA

A

24

40

63

UL 508 AC discharge lamps

A

24

30

40

UL 508 motor load 240 V

Power

hp

3

7.5

10

UL 508 motor load 480 V

Power

hp

5

15

15

UL 508 short circuit at 480 V

K5 fuses

A

25

40

75

kA

5
