BETA Protecting

Overvoltage Protection Devices

Overvoltage protection adapters

6/18

Siemens ET B1 · 10/2008

6

*

You can order this quantity or a multiple thereof.

Overview

Type 3 overvoltage protection adapters for insertion in a

5

socket outlet protect electronic loads against overvoltages from

main power supplies.

However, overvoltages do not just reach loads over power cables.

Telecommunication devices for TAE, ISDN/RDS and RJ12

connection, televisions or radios with aerial connection or satellite

radio connection are all connected to a further power supply

system which may allow overvoltages to reach – and damage –

devices.

Benefits

All type 3 overvoltage protection adapters are fitted with an

LED as a visual status and fault indication

The protection circuit is subject to continuous thermal monitoring.

This ensures constant safe operation for the operator.

Technical specifications

Overvoltage protection adapters

5

,

line

protection

TC analog/

TAE

ISDN/RDSI TV/radio TC analog/

RJ12

TV/SAT

5

SD7 435-0 5SD7 435-2 5SD7 435-3 5SD7 435-5 5SD7 435-6 5SD7 435-7

Standards

IEC 61643-11; EN 61643-11

Approved acc. to

VDE

Rated voltage U

N

(

power supply)

V AC 230

Rated load current

I

L

(

at 30 °C)

A

16

1.5

Rated arrester voltage U

C

(

power supply)

L/N

V AC 275

--

--

--

--

--

V DC --

200

6

72

200

72

L–(N)–PE

V AC 360

--

--

--

--

--

V DC --

200

6

72

200

72

Rated discharge surge current

I

n

(8/20

s)

Core – shield

kA 3

1

0.65

2.5

1

2.5

Core – ground

kA 3

2.5

2.5

5

2.5

5

Combined surge U

oc

kV 4

Response time t

A

ns

25

Protection level U

p

Core – shield/core – ground

kV

1.2

0.9

--

0.7/ 0.9 0.9

0.7/ 0.9

Output voltage limit at 1 kV/ s

Core - core

V

--

360

65

--

--

--

Core – shield

V

--

--

--

700

--

700

Core – ground

V

--

450

900

900

--

900

Residual voltage at

I

n

Core - core

V

--

35

--

--

35

--

Core – shield

V

1200

--

--

30

--

30

Core – ground

V

900

L-/N/PE

30

--

30

30

30

Response time t

A

Core - core

ns

--

25

1

--

25

--

Core – shield

ns

25

--

--

100

--

100

Core – ground

ns

100

L-/N/PE

100

100

100

100

100

Limit frequency f

G

(3

dB)

--

--

--

1.8

GHz --

1.8

GHz

In 100 system (typ.)

--

--

300

kHz --

--

--

In 600 system (typ.)

--

700

kHz --

--

700

kHz --

Temperature range

°C -25 ... +75

Flammability category

Acc. to UL 94

V0

Degree of protection

Acc. to IEC 60529

IP20, with connected conductors

© Siemens AG 2008
