BETA Protecting
SITOR Semiconductor Fuses
SILIZED, NEOZED and DIAZED design
4/22
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
4
■
Overview
SILIZED is the brand name of the NEOZED fuses (D0 fuses) and
the DIAZED fuses (D fuses) with super quick characteristic for
semiconductor protection.
The fuses are used together with fuse bases, fuse screw caps
and accessories of the standard fuse system.
SILIZED fuses protect power semiconductors from the effects of
short circuits because the super quick disconnect characteristic
is far quicker than that of conventional fuses. They protect
expensive devices and system components such as semicon-
ductor contactors, static relays, converters with fuses in the
input and in the DC link, UPS systems and soft starters for
motors up to 100 A.
If using fuse bases and fuse screw caps made of molded plastic,
always take into account the maximum permissible values of
power loss due to the high power dissipation (power loss) of the
SILIZED fuses.
If using these components, the following maximum permissible
power losses apply:
•
NEOZED D02: 5.5 W
•
DIAZED DII: 4.5 W
•
DIAZED DIII: 7.0 W.
For this reason, in some cases, a thermal permanent load of only
50 %
is possible.
The DIAZED screw adapter DII for 25 A is used for the 30 A fuse
link.
■
Benefits
•
SILIZED fuses have an extremely compact design. This
means they have a very small footprint – particularly the
NEOZED version.
•
The rugged and well-known DIAZED design complies with
IEC 60269-3. It is globally renowned and can be used in many
countries.
•
A huge range of fuse bases and accessories are available for
the NEOZED and DIAZED versions of the SILIZED fuses. This
increases the application options in many devices.
■
Technical specifications
■
Selection and ordering data
SILIZED fuse links,
NEOZED design
5
SE1 3
SILIZED fuse links,
DIAZED design
5
SD4
Standards
DIN VDE 0636-3; IEC 60269-3;
DIN VDE 0636-4; IEC 60269-4
Operational class
gR
Characteristic
Super quick
Rated voltage U
n
V AC 400
500
V DC 250
500
Rated current
I
n
A
10 ... 63
16 ... 100
Rated breaking capacity
kA AC 50
kA DC 8
Mounting position
Any, but preferably vertical
Non-interchangeability
Using adapter sleeves
Using screw adapter or adapter sleeves
Resistance to climate
°C Up to 45 at 95 % rel. humidity
Ambient temperature
°C -5 ... +40, humidity 90 % at 20
Size
I
e
U
e
Breaking
I
2
t value
Power
loss
DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
A
V AC/
V DC
A
2
s
W
Unit(s) Unit(s) kg
SILIZED fuse links, NEOZED design
Operational class gR
D01
10
400/250 73
6.9
B
5
SE1 310
016 1
10 0.006
16
120
6.2
B
5
SE1 316
016 1
10 0.007
D02
20
190
8.1
B
5
SE1 320
016 1
10 0.012
25
215
8.2
B
5
SE1 325
016 1
10 0.012
35
470
16.7
B
5
SE1 335
016 1
10 0.012
50
1960
12.0
B
5
SE1 350
016 1
10 0.013
63
4230
15.5
B
5
SE1 363
016 1
10 0.014
