NEOZED fuse systems
3/6
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
3
■
Selection and ordering data
Size
Number of
poles
I
n
Identifi-
cation
color
MW DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
A
Unit(s) Unit(s) kg
NEOZED fuse links
Rated voltage 400 V AC/250 V DC
Operational class gG
D01
2
Pink
}
5
SE2 302
016 1
10 0.006
4
Brown
}
5
SE2 304
016 1
10 0.006
6
Green
}
5
SE2 306
016 1
10/500 0.006
10
Red
}
5
SE2 310
016 1
10/500 0.007
13
Black
A
5
SE2 013-2A
016 1
10 0.007
16
Gray
}
5
SE2 316
016 1
10/500 0.007
D02
20
Blue
}
5
SE2 320
016 1
10 0.012
25
Yellow
}
5
SE2 325
016 1
10 0.013
32
Black
B
5
SE2 332
016 1
10 0.014
35
Black
}
5
SE2 335
016 1
10 0.014
40
Black
B
5
SE2 340
016 1
10 0.014
50
White
}
5
SE2 350
016 1
10 0.015
63
Copper
}
5
SE2 363
016 1
10 0.016
D03
80
Blue
}
5
SE2 280
016 1
10 0.039
100
Red
}
5
SE2 300
016 1
10 0.042
MINIZED switch disconnectors with fuses
Using draw-out technology and touch protection to BGV A3
(
adapter sleeves not included in delivery)
D02
1
P
63
1.5
}
5
SG7 113
016 1
1
0.145
1
P+N 63
3
B
5
SG7 153
016 1
1
0.267
2
P
63
3
B
5
SG7 123
016 1
1
0.283
3
P
63
4.5
}
5
SG7 133
016 1
1
0.421
3
P+N 63
6
B
5
SG7 163
016 1
1
0.540
Versions for Austria only,
with permanently fitted adapter sleeves,
incl. fuse link
D02
3
P
25
4.5
B
5
SG7 133-8BA25
016 1
1
0.420
35
B
5
SG7 133-8BA35
016 1
1
0.420
50
B
5
SG7 133-8BA50
016 1
1
0.420
Reducers
For fuse links D01
in MINIZED switch disconnectors D02
C
5
SH5 527
016 1
10/100 0.003
Auxiliary switches (AS)
For MINIZED switch disconnectors D02
1
NO + 1 NC
For technical specifications,
see chapter Miniature Circuit Breakers –>
Additional components
0.5
}
5
ST3 010
027 1
1
0.050
