BETA Protecting
Low-Voltage Fuse Systems
NEOZED fuse systems
3/5
Siemens ET B1 · 10/2008
3
*
You can order this quantity or a multiple thereof.
■
Technical specifications
NEOZED fuse links
5
SE2
Standards
IEC 60269-3; DIN VDE 0636-3
Operational class
gG
Rated voltage U
n
V AC 400
V DC 250
Rated current
I
n
A
2 ... 100
Rated breaking capacity
kA AC 50
kA DC 8
Non-interchangeability
Using adapter sleeves
Resistance to climate
°C
Up to 45 at 95 % rel. humidity
Ambient temperature
°C
-5 ...
+40, humidity 90 % at 20
MINIZED
switch dis-
connectors
MINIZED
fuse switch
disconnectors
Fuse bases,
made of ceramic
Comfort
bases
Fuse bases
D02
5
SG7 1
D01
5
SG7 6
D01
5
SG1 5
5
SG5 5
D02
5
SG1 6
5
SG5 6
D03
5
SG1 8
D01/02
5
SG1 .01
5
SG5 .01
5
SG1 .30
5
SG1 .31
5
SG5 .30
Standards
DIN VDE 0638;
DIN VDE 0660-107
IEC 60269-3; DIN VDE 0636-3
IEC/EN 60947-3
Main switch characteristic
EN 60204-1
Yes
--
--
Insulation characteristic
EN 60664-1
Yes
--
Rated voltage
U
n
V AC 230/400, 240/415
400
V DC
250
• 1
P
V DC 65
48
--
• 2
P in series
V DC 130
110
--
Rated current
I
n
A
63
16
16
63
100
16/63
16/63
Rated insulation voltage
V AC 500
400
--
Rated impulse withstand voltage
kV AC 6
2.5
--
Overvoltage category
4
--
--
Utilization category
acc. to VDE 0638
•
AC-22
A
63
16
--
Utilization category
acc.to EN 60947-3
•
AC-22 B
A
63
16
--
•
AC-23 B
A
35
--
--
•
DC-22 B
A
63
--
--
Sealable
when switched on
Yes
Yes, with sealable screw caps
Mounting position
Any, but preferably vertical
Reduction factor
of
I
n
with 18 pole
•
Side-by-side mounting
0.9
--
•
On top of one another,
with vertical standard mounting rail
0.87
--
Degree of protection
acc. to IEC 60529
IP20, with connected conductors
Terminals
with touch-protection acc. to BGVA
Yes
No
Yes
Ambient temperature
°C
-5 ...
+40, humidity 90 % at 20
Terminal versions
--
--
B
K, S
K/S
--
--
Conductor cross-sections
•
Solid and stranded
mm
2
1.5 ... 35
1.5 ... 16
1.5 ... 4 1.5 ... 25 10 ... 50 0.75 ... 35 1.5 ... 35
•
Flexible, with end sleeve
mm
2
1.5 ... 35
1.5
1.5
1.5
10
--
--
•
Finely stranded, with end sleeve
mm
2
--
--
0.75 ... 25 --
--
--
--
Tightening torque
Nm 4
1.2
1.2
2
3.5/2.5 2.5 ... 3
3
