20/100 Small enclosures, basic enclosures
Small enclosures CI-K
2010 CA08103002Z-EN
SmallenclosuresCI-KTechnical data
CI-K1 CI-K2 CI-K2...-80-A
CI-K2...-80-K
CI-K3 CI-K4 CI-K5
General
Standards IEC/EN 60529
DIN 43660
EN 50262
Climatic proofing Damp heat, constant, to IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature °C -25 - 70
Ambient air temperature with push-through cable entry °C -25…40
Protection type Front IP65 Front IP30 Front IP65
The degree of protection specifications do not apply to CI-K2-80-A
Protection type with push-through cable entry IP65 IP30 IP65
Radiated heat dissipation
￫Page 20/101
Material properties
Material
Base, cover Glass-fibre reinforced polycarbonate
Surface treatment Corrosion-resistant
Color
Base RAL 9005, black (matt)
Cover Enclosure cover RAL 7035, light grey (matt)
Material properties
Electrical
Creepage resistance to IEC 60112
Base CTI 175
Cover CTI 175
Surface treatment to IEC 60093 Ω x 1013 > 1
Dielectric strength to IEC 60243-1 kV/mm 30
Thermal
Continuous thermal stability
Housing °C -40…120
Sealing °C -40…80
Mechanical
IK code to EN 50102 04 06 06 06 06 06
Weight of fitted components
Per mounting rail kg 0.2 0.7 0.7 0.85 0.75 0.65
With mounting plate kg – – 0.7 0.85 0.9 1
Chemical resistance
Base, cover
Resistant Acids < 10 %, mineral oil, petrol, grease, saline solutions
Partially resistant Acids > 10 %, Alcohol
Non-resistant Alkalis, benzol
Push-through membrane (CI-K1/CI-K2) and sealing material
Resistant Acids < 10 %, alkalis, alcohol,
saline solutions
– – –
Partially resistant Acids < 10 %, grease, benzene – – –
Non-resistant Mineral oil, petrol – – –
Atmospheric
Saline spray IEC 60068-2-11
UV resistance Beneath protective canopy
Water absorption to EN ISO 62 % 0.29
Flammability characteristics
Glow-wire test
Base, cover
Glow wire to VDE 0471 Part 2 °C 960/1 mm thick
According to UL 94 VO/1.5 mm thickness
Push-through membrane (CI-K1/CI-K2) and sealing
material
To VDE 0471 Part 2 °C 650/1 mm thick – – –
According to UL 94 HB – – –
Halogen free Yes – – –
Notes The degree of protection specifications do not apply to CI-K2-80-A
CI-K
