18/104 IZM circuit-breakers, IN switch-disconnectors

Circuit-breaker IZM26

2010 CA08103002Z-EN

www.eaton.com

IZM32N…16… IZM32N…20… IZM32N…25…

General

Standards

IEC/EN 60947

Ambient temperature

Storage

°C

-40 - +70 (Devices with LCD display -20 - +70)

Operation (open)

°C

-25 - +70 (Devices with LCD display -20 - +70)

Built-in position

Utility category

B

B

B

Protection type

IP20, IP54 with protective cover

Direction of incoming supply

Any

Main contacts

Rated operational current = Rated uninterrupted current

I

n

= I

u

A

1600

2000

2500

Rated uninterrupted current at 50 °C

1)

I

u

A

1600

2000

2500

Rated uninterrupted current at 60 °C

1)

I

u

A

1600

2000

2500

Rated uninterrupted current at 70 °C

1)

I

u

A

1600

2000

2500

Rated impulse withstand voltage

U

imp

V AC 8000

8000

8000

Rated operational voltage

U

e

V AC 690

690

690

Use in IT electrical power networks up to U = 440 V

I

IT

kA 23

28

39

Use in IT electrical power networks up to U = 690 V

I

IT

kA 23

28

39

Overvoltage category/pollution degree

III/3

III/3

III/3

Rated insulation voltage

U

i

V

1000

1000

1000

Switching capacity

Rated short-circuit making capacity

Upto 440V 50/60Hz I

cm

kA 179

179

179

Upto 690V 50/60Hz I

cm

kA 179

179

179

Rated short-time withstand current 50/60 Hz t = 1 s

I

cw

kA 85

85

85

t = 3 s

I

cw

kA 65

65

65

Rated short-circuit breaking capacity I

cn

IEC/EN 60947 Operating sequence I

cu

O-t-CO

Up to 240 V 50/60 Hz

I

cu

kA 85

85

85

Up to 440 V 50/60 Hz

I

cu

kA 85

85

85

Up to 690 V 50/60 Hz

I

cu

kA 85

85

85

Up to 1100 V 50/60 Hz

I

cu

kA –

IEC/EN 60947 Operating sequence I

cs

O-t-CO-t-CO

Up to 240 V 50/60 Hz

I

cs

kA 85

85

85

Up to 440 V 50/60 Hz

I

cs

kA 85

85

85

Up to 690 V 50/60 Hz

I

cs

kA 85

85

85

Up to 1100 V 50/60 Hz

I

cs

kA –

Switching times

Total opening delay

ms

30

30

30

Closing delay

ms

35

35

35

Closing delay electrical (via closing release)

ms

40

40

40

Opening delay electrical ( via shunt release / undervoltage release)

ms

35/70

35/70

35/70

Opening delay via trip electronics (non-delayed short-circuit release)

ms

35

35

35

Durability

Mechanical, without maintenance

Operations

10000

10000

8000

Mechanical, with maintenance

Operations

16000

16000

12800

Electrical, without maintenance

Operations

10000

10000

8000

Electrical, with maintenance

Operations

10000

10000

8000

Maximum operating frequency

Operations/h

60

60

60

Heat dissipation at rated operational current I

n

3-phase symmetric loading

Fixed

W 120

190

200

Withdrawable

W 240

380

500

Weight

Fixed

3 pole

kg

68

68

70

4 pole

kg

86

86

89

Withdrawable

3 pole

kg

80

80

88

4 pole

kg

102

102

115

Empty cassette

3 pole

kg

34

34

58

4 pole

kg

38

38

60

Notes

1)

Permissible continuous current for circuit-breakers used at different temperatures within switchgear.

The expected internal temperatures can be estimated according to the applicable IEC regulations.

30˚ 30˚

30˚ 30˚

IZM…
