18/106 IZM circuit-breakers, IN switch-disconnectors

Circuit-breaker IZM26

2010 CA08103002Z-EN

www.eaton.com

IZM32H…32… IZM32S…

IZM40N…40…

General

Standards

IEC/EN 60947

Ambient temperature

Storage

°C -40 - +70 (Devices with LCD display -20 - +70)

Operation (open)

°C -25 - +70 (Devices with LCD display -20 - +70)

Built-in position

Utility category

B

B

B

Protection type

IP20, IP54 with protective cover

Direction of incoming supply

Any

Main contacts

Rated operational current = Rated uninterrupted

current

I

n

= I

u

A 3200

3200

4000

Rated uninterrupted current at 50 °C

1)

I

u

A 3100

3100

4000

Rated uninterrupted current at 60 °C

1)

I

u

A 2800

2800

4000

Rated uninterrupted current at 70 °C

1)

I

u

A 2550

2550

3776

Rated impulse withstand voltage

U

imp

V AC 8000

8000

12000

Rated operational voltage

U

e

V AC 690

1100

690

Use in IT electrical power networks up to U = 440 V

I

IT

kA 39

48

Use in IT electrical power networks up to U = 690 V

I

IT

kA 39

39

Overvoltage category/pollution degree

III/3

III/3

III/3

Rated insulation voltage

U

i

V

1000

1100

1000

Switching capacity

Rated short-circuit making capacity

Up to 440 V 50/60 Hz I

cm

kA 210

210

179

Up to 690 V 50/60 Hz I

cm

kA 179

210

137

Rated short-time withstand current 50/60 Hz

t = 1 s

I

cw

kA 85

85

t = 3 s

I

cw

kA 65

65

Rated short-circuit breaking capacity I

cn

IEC/EN 60947 Operating sequence I

cu

O-t-CO

Up to 240 V 50/60 Hz

I

cu

kA 100

85

Up to 440 V 50/60 Hz

I

cu

kA 100

85

Up to 690 V 50/60 Hz

I

cu

kA 85

65

Up to 1100 V 50/60 Hz

I

cu

kA –

25

IEC/EN 60947 Operating sequence I

cs

O-t-CO-t-CO

Up to 240 V 50/60 Hz

I

cs

kA 100

85

Up to 440 V 50/60 Hz

I

cs

kA 100

85

Up to 690 V 50/60 Hz

I

cs

kA 85

65

Up to 1100 V 50/60 Hz

I

cs

kA –

25

Switching times

Total opening delay

ms

30

30

30

Closing delay

ms

35

35

35

Closing delay electrical (via closing release)

ms

40

40

40

Opening delay electrical ( via shunt release / undervoltage

release)

ms

35/70

35/70

35/70

Opening delay via trip electronics (non-delayed short-circuit

release)

ms

35

35

35

Durability

Mechanical, without maintenance

Operations

8000

8000

5000

Mechanical, with maintenance

Operations

12800

12800

8000

Electrical, without maintenance

Operations

8000

8000

3000

Electrical, with maintenance

Operations

8000

8000

3000

Maximum operating frequency

Operations/h

60

60

60

Heat dissipation at rated operational current I

n

3-phase symmetric loading

Fixed

W 320

320

560

Withdrawable

W 800

800

1100

Weight

Fixed

3 pole

kg

70

70

83

4 pole

kg

89

89

105

Withdrawable

3 pole

kg

88,

88

98

4 pole

kg

115

115

121

Empty cassette

3 pole

kg

60

60

60

4 pole

kg

73

73

73

Notes

1)

Permissible continuous current for circuit-breakers used at different temperatures within switchgear.

The expected internal temperatures can be estimated according to the applicable IEC regulations.

30˚ 30˚

30˚ 30˚

IZM…
