IZM circuit-breakers, IN switch-disconnectors
Selectivity: incoming circuit-breaker, outgoing circuit-breaker
2010 CA08103002Z-EN
www.eaton.com18/99
I
n
: Rated operational current
I
u
: Rated uninterrupted current
I
cu
: Rated short-circuit breaking
capacity
I
i
: Set value non-delayed short-circuit
releases
Selectivity 415 V AC
between circuit-breakers enables the separate
isolation of faulty system sections.
Selectivity exists between incoming circuit-
breaker 1 and outgoing circuit-breaker 2 if,
only outgoing breaker 2 trips at position 2 during
a short-circuit.
System sections 3 and 4 continue to operate.
Selection:
Provided that the short-circuit current does not exceed
those values specified (I
cc rms
).
These details represent the limits of selectivity.
Both circuit-breakers will switch off with higher
short-circuit currents.
On IZM circuit-breakers with V, U, P releases, the delay
time t
sd
must be at least 100 ms longer than the delay
time of the next downstream levels (2, 3, 4).
Incoming
circuit-
breaker (1)
IZM...63-V
IZM...63-U
IZM63...-P
I
n
[A]
4000 4000 5000 5000 6300 6300 4000 4000 5000 5000 6300 6300 4000 4000 5000 5000 6300 6300
I
cu
[kA] 85 100 85 100 85 100 85 100 85 100 85 100 85 100 85 100 85 100
I
i
[A]
48000 48000 60000 60000 63000 63000 48000 48000 60000 60000 63000 63000 48000 48000 60000 60000 63000 63000
Outgoing
circuit-
breaker (2)
I
u
[A]
I
cu2(415V)
[kA]
N H N H N H N H N H N H N H N H N H
Prospective short-circuit current (I
cc rms
in kA)
NZMB(C)(N)(H)
1-A(M)…
20 25 - 100 T T T T T T T T T T T T T T T T T T
25 25 - 100 T T T T T T T T T T T T T T T T T T
32 25 - 100 T T T T T T T T T T T T T T T T T T
40 25 - 100 T T T T T T T T T T T T T T T T T T
50 25 - 100 T T T T T T T T T T T T T T T T T T
63 25 - 100 T T T T T T T T T T T T T T T T T T
80 25 - 100 T T T T T T T T T T T T T T T T T T
100 25 - 100 T T T T T T T T T T T T T T T T T T
125 25 - 100 T T T T T T T T T T T T T T T T T T
160 25 - 100 T T T T T T T T T T T T T T T T T T
NZMB(C)(N)(H)
2-A(M)(V)…
20 25 - 150 T T T T T T T T T T T T T T T T T T
25 25 - 150 T T T T T T T T T T T T T T T T T T
32 25 - 150 T T T T T T T T T T T T T T T T T T
40 25 - 150 T T T T T T T T T T T T T T T T T T
50 25 - 150 T T T T T T T T T T T T T T T T T T
63 25 - 150 T T T T T T T T T T T T T T T T T T
80 25 - 150 T T T T T T T T T T T T T T T T T T
90 25 - 150 T T T T T T T T T T T T T T T T T T
100 25 - 150 T T T T T T T T T T T T T T T T T T
125 25 - 150 T T T T T T T T T T T T T T T T T T
140 25 - 150 T T T T T T T T T T T T T T T T T T
160 25 - 150 T T T T T T T T T T T T T T T T T T
200 25 - 150 T T T T T T T T T T T T T T T T T T
220 25 - 150 T T T T T T T T T T T T T T T T T T
250 25 - 150 T T T T T T T T T T T T T T T T T T
300 25 - 150 T T T T T T T T T T T T T T T T T T
NZMC(N)(H)
3-A(M)(V)…
220 36 - 150 T T T T T T T T T T T T T T T T T T
250 36 - 150 T T T T T T T T T T T T T T T T T T
320 36 - 150 T T T T T T T T T T T T T T T T T T
350 36 - 150 T T T T T T T T T T T T T T T T T T
400 36 - 150 T T T T T T T T T T T T T T T T T T
450 36 - 150 T T T T T T T T T T T T T T T T T T
500 36 - 150 T T T T T T T T T T T T T T T T T T
630 36 - 150 T T T T T T T T T T T T T T T T T T
NZMN(H)
4-A(M)(V)…
550 50 - 100 T T T T T T T T T T T T T T T T T T
630 50 - 100 T T T T T T T T T T T T T T T T T T
800 50 - 100 T T T T T T T T T T T T T T T T T T
875 50 - 100 T T T T T T T T T T T T T T T T T T
1000 50 - 100 T T T T T T T T T T T T T T T T T T
1250 50 - 100 T T T T T T T T T T T T T T T T T T
1400 50 - 100 T T T T T T T T T T T T T T T T T T
1600 50 - 100 T T T T T T T T T T T T T T T T T T
Notes
B = Basic switching capacity, N = Normal switching capacity, H = High switching capacity, T = Total selectivity
2
1
3 4
IZM63...
