IZM circuit-breakers, IN switch-disconnectors
IN26 switch-disconnectors
2010 CA08103002Z-EN
www.eaton.com18/39
IN26 switch-disconnectors
I
cm
I
cm
:
at Ue = 440/690 V AC
Rated short-circuit making capacity
(Peak value) at rated operational voltage U
e
Basic
switching capacity
(B)
Normal switching
capacity (N)
High switching
capacity (H)
(S)
Switch-disconnector
Rated operational current I
n
A
440/690 V AC
I
cm
kA
440/690 V AC
I
cm
kA
440/690 V AC
I
cm
kA
1100 V AC
I
cm
kA
IN20
800 - 1600
105
143
-
-
IN20
2000
105
143
-
-
IN32
800 - 1600
143
187
-
-
IN32
2000 - 3200
143
187
-
-
IN40
4000
-
187
220
-
IN63
4000 - 6300
-
187
220
-
IN32S
3200
-
-
-
52
I
cm
I
cw
I
cw
:
at U
e
= 440/690 V AC
at t = 1 s/t = 3 s
Rated short-time withstand current
Basic
switching capacity (B)
Normal switching capacity (N)
High switching capacity (H)
Switch-disconnector
Rated operational current
I
n
A
t = 1 s/t = 3s
I
cw
/I
cw
kA/kA
t = 1 s/t = 3s
I
cw
/I
cw
kA/kA
t = 1 s/t = 3s
I
cw
/I
cw
kA/kA
IN20
800 - 1600
50/-
65/40
-
IN20
2000
50/30
65/40
-
IN32
800 - 1600
65/-
85/65
-
IN32
2000 - 3200
65/50
85/65
-
IN40
4000
-
85/65
100/65
IN63
4000 - 6300
-
85/65
100/65
IN26
