2010 CA08103002Z-EN

Circuit-breakers, switch-disconnectors

Circuit-breakers, electronic releases, 4 pole

Fixed mounting

with box terminals

Plug-in/withdrawable units

Part no.

Article no.

Price

See price

list

Part no.

Article no.

Price

See price

list

Std. pack

Notes

Order base separately

B = box terminals

S = screw terminals

For further terminal types see

accessories

Terminals as

accessory

NZMN2-4-VE100-SVE

113275

1 off

IEC/EN 60947-2

Set value for neutral

conductor is same as set

value I

r

for main pole.

R.m.s. value measurement

and “thermal memory”

Adjustable delay setting t

r

• 2 – 20 s at 6 x I

r

and infinite

(without overload release)

– NZM...3-4-VE400(630):

2 – 14 s at 6 x I

r

and

infinite (without overload

release)

Adjustable delay t

sd

• Steps: 0, 20, 60, 100, 200,

300, 500, 750, 1000 ms

i

2

t constant function

• NZM2 fixed OFF

• NZM3, NZM4 switchable

NZMN2-4-VE160-SVE

113277

NZMN2-4-VE160/100-SVE

113278

NZMN2-4-VE250-SVE

113280

NZMN2-4-VE250/160-SVE

113281

NZMN3-4-VE400-AVE

110876

NZMN3-4-VE400/250-AVE

113546

NZMN3-4-VE630-AVE

110877

NZMN3-4-VE630/400-AVE

113548

Withdrawable units as

accessories

17/39

NZM...-4-VE

HPL17039EN
