DS7 soft starters
Accessories
2010 CA08103002Z-EN
9/21
Accessories
Rated
operational
current
Maximum
power
loss
Frame size/
inside
micrometer
For use with Part no.
Article no.
Price
See price list
Std. pack Information relevant for export to
North America
Pv
A W mm
Accessories
Superfast semiconductor fuses
16 5 10 x 38 DS7-34…SX004N0-… 50.179.06-16
232077
10 off Product Standards UL 248-13
CE marking
UL File No. E180276
UL CCN JFHR2
CSA File No. UL report applies
to both US and
Canada
CSA Class No. JFHR8
NA Certification UL Recognized,
certified by UL
for use in Canada
Max. Voltage Rating 660 V
25 7 22 x 58 DS7-34…SX007N0-… 50.140.06-25
138284
1 off
32 9 80 DS7-34…SX009N0-…
DS7-34…SX012N0-…
20.282.20-32
138285
1 off
50 15 22 x 58 DS7-34…SX016N0-… 50.140.06-50
232079
10 off
63 16 22 x 58 DS7-34…SX024N0-… 50.140.06-63
232080
10 off
80 18 22 x 58 DS7-34…SX032N0-… 50.140.06-80
232081
10 off
Fuse links
100 22 80 DS7-34…SX041N0-… 20.282.20-100
106654
6 off Product Standards UL 248-13 CE
marking
UL File No. E180276
UL CCN JFHR2
CSA File No. UL report applies
to both US and
Canada
CSA Class No. JFHR8
NA Certification UL Recognized,
certifiedbyULfor
use in Canada
Max. Voltage Rating 660 V
125 24 80 DS7-34…SX055N0-… 20.282.20-125
232087
6 off
200 44 80 DS7-34…SX070N0-…
DS7-34…SX081N0-…
DS7-34…SX100N0-…
20.610.32-200
106475
3 off
350 61 80 DS7-34…SX135N0-… 20.610.32-350
221161
2 off
400 70 80 DS7-34…SX160N0-… 20.610.32-400
106476
3 off
500 72 80 DS7-34…SX200N0-… 20.610.32-500
221163
2 off
Fuse bases
– – 10 x 38 50.179.06-… 51.063.04
232082
12 off Product Standards UL 512;
CE marking
UL File No. E186970
UL CCN IZLT2
– – 22 x 58 50.140.06-… 51.060.04
232084
6 off
– – 80 20.282.20-…
20.189.20-…
21.189.01
232064
5 off
– – 80 20.6xx.32-…
20.6...32-...
21.313.02
232076
2 off
