Motor-protective circuit-breakers PKZM01, PKZM0, PKZM4, PKE
Type E starters
2010 CA08103002Z-EN
7/35
Rating data for approved types1)
UL 508/CSA C 22.2 No. 14 For use with Pilot Duty General Use
Accessories
Standard auxiliary contacts NHI11-PKZ0 PKZM0(-T)
PKZM4
A 600, Q 300 5 A – 600 V AC
1 A – 250 V DC
–
NHI12-PKZ0
NHI21-PKZ0
NHI2-11S-PKZ0
NHI-E-11-PKZ0 E150 0.5 A – 250 V AC –
NHI-E-10-PKZ0
Early-make auxiliary contacts VHI20-PKZ0 PKZM0(-T) E150 0.5 A – 250 V AC –
VHI20-PKZ01 PKZM01
Trip indicators AGM2-10-PKZ0 PKZM0(-T)
PKZM4
A 600, Q 300 5 A – 600 V AC
1 A – 250 V DC
–
AGM2-01-PKZ0
Shunt release A-PKZ0(...) PKZM0(-T)
PKZM4
– – Actuating voltages and ordering
information ￫ Products for the
German market U-PKZ0(...)
Auxiliary contact for contact
module
HI11-S/EZ-PKZ0 PKZM0 A 600, Q 300 5 A – 600 V AC
1 A – 250 V DC
–
Notes 1) Devices for world markets IEC = UL/CSA
Motor-protective circuit-breakers PKZM0(4) used as "Manual self-protected Motor Starters" – UL 508 Type E
Maximum motor output
AC
Setting ranges Interrupting Capacity =
Short Circuit Current (SCCR)
Components
200 V
208 V
230 V
240 V
460 V
480 V
575 V
600 V
Overload
releases
Short-circuit
releases
240 V 480Y/
277 V2)
600Y/
347 V2)
Motor
Protector
Accessories
[HP] [HP] [HP] [ HP] [A] [A] [kA] [kA] [kA] Part no. Part no.
1) 0.1 – 0.16 2.2 65 65 50 PKZM0-0.16 BK25/3-PKZ0-E
0.16 – 0.25 3.4 65 65 50 PKZM0-0.25 BK25/3-PKZ0-E
0.25 – 0.4 5.6 65 65 50 PKZM0-0.4 BK25/3-PKZ0-E
0.4 – 0.63 8.8 65 65 50 PKZM0-0.63 BK25/3-PKZ0-E
0.63 – 1 14 65 65 50 PKZM0-1 BK25/3-PKZ0-E
¾ ¾ 1 – 1.6 22 65 65 50 PKZM0-1.6 BK25/3-PKZ0-E
½ ½ 1 1½ 1.6 – 2,5 35 65 65 50 PKZM0-2.5 BK25/3-PKZ0-E
¾ ¾ 2 3 2.5 – 4 56 65 65 50 PKZM0-4 BK25/3-PKZ0-E
1 1½ 3 5 4 – 6.3 88 65 65 50 PKZM0-6.3 BK25/3-PKZ0-E
3 3 7½ 10 6.3 – 11 140 65 65 50 PKZM0-10 BK25/3-PKZ0-E
3 3 7½ – 9 – 12 168 65 65 – PKZM0-12 BK25/3-PKZ0-E
3 5 10 – 10 – 16 224 42 42 – PKZM0-16 BK25/3-PKZ0-E
5 – – – 16 – 20 280 18 18 – PKZM0-20 BK25/3-PKZ0-E
– 7½ 15 – 20 – 25 350 18 18 – PKZM0-25 BK25/3-PKZ0-E
7½ 10 20 – 24 – 32 448 18 18 – PKZM0-32 BK25/3-PKZ0-E
3 5 10 10 10 – 16 224 65 65 25 PKZM4-16 BK50/3-PKZ4-E
5 7½ 15 20 16 – 27 350 65 65 25 PKZM4-25 BK50/3-PKZ4-E
7½ 10 20 30 24 – 34 448 65 65 25 PKZM4-32 BK50/3-PKZ4-E
10 – 30 30 32 – 40 560 65 65 25 PKZM4-40 BK50/3-PKZ4-E
– 15 30 – 40 – 52 700 65 65 – PKZM4-50 BK50/3-PKZ4-E
– – 40 – 50 – 56 812 65 65 – PKZM4-58 BK50/3-PKZ4-E
– – 40 – 52 – 58 882 65 – – PKZM4-63 BK50/3-PKZ4-E
Notes 1) Calculate motor power in this range according to the rated current. Stated values to NEC Table 430 -150
2) Suitable for networks with grounded star-point
