4/28 Cam switches, switch-disconnectors
Switch-disconnectors – On-Off switches
2010 CA08103002Z-EN
Flush mounting
Contact sequence Front
plate no.
Main
contacts
Pole
Auxiliary
contacts
Max. motor rating:
AC-23A
400/415 V
50/60 Hz
Rated
uninterrupted
current
Front IP65
N/O N/O N/C 400 V
P
kW
Iu
A
Part no.
Article no.
Price
See
price
list
Std. pack
On-Off switches as an emergency switching off/emergency stop device
With red thumb-grip and yellow front plate
To IEC/EN 60204-1, VDE 113 Part 1
1 0 0 6.5 20 T0-1-8200/E-RT 1)
009474
1 Off
13 32 T3-1-8200/E-RT 3)
017025
22 63 T5B-1-8200/E-RT4)
094280
30 100 T5-1-8200/E-RT
097225
1 Off
2 0 0 6.5 20 T0-1-102/E-RT1)
009046
1 Off
13 32 T3-1-102/E-RT1)
016318
22 63 T5B-1-102/E-RT4)
094470
3 0 0 6.5 20 T0-2-1/E-RT 1)
011082
13 25 P1-25/E-RT 1)
002388
15 32 P1-32/E-RT 1)
003197
37 63 P3-63/E-RT 7)
005743
50 100 P3-100/E-RT7)
007189
3 + N 0 0 6.5 20 T0-2-8900/E-RT 1)
207399
FS 908
ON
OFF
1 2
0 1
1 2 3 4
0 1
1 2 3 4 5 6
0 1
1 2 3 4 5 6 7 8
0 1
Information relevant for export to North America
1) 2)
Product Standards UL 508; CSA-C22.2 No. 14-05;
IEC/EN 60947-3; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
Suitable for Branch circuits, suitable as motor
disconnect
Degree of Protection IEC: IP65; UL/CSA Type 3R, 12
Product Standards UL 508; CSA-C22.2 No. 14-05;
IEC/EN 60947-3; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
Suitable for Branch circuits, suitable as
motor disconnect
Degree of Protection IEC: IP30; UL/CSA Type: –
6) 7)
Product Standards UL 508; CSA-C22.2 No. 14-05;
CSA-C22.2 No. 94; IEC/EN 60947-3;
CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
Suitable for Branch circuits, suitable as motor
disconnect
Degree of Protection IEC: IP65; UL/CSA Type: –
Product Standards UL 508; CSA-C22.2 No. 14-05;
CSA-C22.2 No. 94; IEC/EN
60947-3; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
Suitable for Branch circuits, suitable as
motor disconnect
Degree of Protection IEC: IP65; UL/CSA Type 3R, 12
HPL04028EN
