4/34 Cam switches, switch-disconnectors
Switch-disconnectors – changeover switches
2010 CA08103002Z-EN
Flush mounting
Contact sequence Front plate no. Main contacts
Pole
Max. operating
power
AC-23A
400/415 V
50/60 Hz
Rated
uninterrupted
current
Front IP65
N/O 400 V
P
kW
Iu
A
Part no.
Article no.
Price
See
price list
Std. pack
Changeover switches
With black thumb-grip and front plate
Without emergency switching off/emergency stop function
4 13 32 T3-4-8902/E 1)
215222
1 Off
22 63 T5B-4-8902/E5)
207430
30 100 T5-4-8902/E
207418
4 6.5 20 T0-4-8213/E 1)
031726
13 32 T3-4-8213/E 1)
076075
22 63 T5B-4-8213/E5)
092112
30 100 T5-4-8213/E
096014
4 6.5 20 T0-4-8294/E 1)
010371
13 32 T3-4-8294/E 1)
002513
22 63 T5B-4-8294/E5)
092084
30 100 T5-4-8294/E
095986
1 Off
1 2 3 4 5 6 7 8 9 10 11 12 13 14
0
15 16
Netz
Notstrom
0
FS 161629
NETZ
NOT-
STROM
1 2 3 4 5 6 7 8 9 10 11 12 13 14
1 0 2
15 16
FS 684
0
1 2
1 2 3 4 5 6 7 8 9 10 11 12 13 14
1 0 2
15 16
FS 953
0
1 2
Information relevant for export to North America
1) 2)
Product Standards UL 508; CSA-C22.2 No. 14-05;
IEC/EN 60947-3; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
Suitable for Branch circuits
Degree of Protection IEC: IP65; UL/CSA Type 3R, 12
Product Standards UL 508; CSA-C22.2 No. 14-05;
IEC/EN 60947-3; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed, CSA certified
Suitable for Branch circuits
Degree of Protection IEC: IP30; UL/CSA Type: –
T, P HPL04034EN
