Sensors
Comet Series, FO cables
2010 CA08103002Z-EN
Optical sensors 3/85
Diffuse reflective sensor, forward viewing
20 - 264 V AC
15 - 30 V DC
NPN 50 2 m connection cable With background
suppression
(Perfect Prox)
Visible red 13104A6513
135602
1 off
plug connector M12 x 1 13104AQD03
135604
2 m connection cable 13105A6513
135614
plug connector M12 x 1 13105AQD03
135616
100 2 m connection cable Infrared 13101A6513
135586
100 plug connector M12 x 1 13101AQD03
135588
150 2 m connection cable – 13107AS6513
135626
plug connector M12 x 1 13107ASQD03
135628
2 m connection cable With background
suppression
(Perfect Prox)
13108A6513
135634
plug connector M12 x 1 13108AQD03
135636
200 2 m connection cable – 13106A6513
135618
200 plug connector M12 x 1 13106AQD03
135620
225 2 m connection cable With background
suppression
(Perfect Prox)
13103A6513
135594
225 plug connector M12 x 1 13103AQD03
135596
610 2 m connection cable – 13100A6513
135578
610 plug connector M12 x 1 13100AQD03
135580
Diffuse reflective sensor, right-angle
20 - 264 V AC
15 - 30 V DC
NPN 50 2 m connection cable With background
suppression
(Perfect Prox)
Visible red 13104R6513
135606
1 off
50 plug connector M12 x 1 13104RQD03
135608
100 plug connector M12 x 1 13104RS5003
135610
100 2 m connection cable 13104RS5013
135612
150 2 m connection cable – Infrared 13107RS6513
135630
plug connector M12 x 1 13107RSQD03
135632
2 m connection cable With background
suppression
(Perfect Prox)
13108R6513
135638
plug connector M12 x 1 13108RQD03
135640
200 2 m connection cable – 13106R6513
135622
200 plug connector M12 x 1 13106RQD03
135624
225 2 m connection cable With background
suppression
(Perfect Prox)
13103R6513
135598
225 plug connector M12 x 1 13103RQD03
135600
610 2 m connection cable – 13100R6513
135582
610 plug connector M12 x 1 13100RQD03
135584
Information relevant for export to North America
Product Standards UL 508; CSA-C22.2 No. 14;
IEC60947-5-2; CE marking
UL File No. E166051
UL CCN NRKH, NRKH7
CSA File No. 50513
CSA Class No. 3211-07
NA Certification UL Listed, CSA certified
Max. Voltage Rating 264 V AC, 30 V DC
Degree of Protection IEC: IP68, IP69K; UL/CSA Type: -
Rated operating
voltage
Switching
type
Rated switching
distance
Connection options Description Type of
light
Part no.
Article no.
Price
Seeprice
list
Std. pack
Sn
mm
