Sensors
E57 Global Series
2010 CA08103002Z-EN
Inductive Sensors 3/43
InductiveSensorsE57GlobalSeries
InductiveSensorsE57GlobalSeries
E57-...(3-wire)
E57-08... E57-12... E57-18...
E57-12GE... E57-12GS... E57-12GU... E57-18GE...
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -0 - +60 -25 - +70 -25 - +70 -25 - +70 -25 - +70
Protection type IP67 IP67 IP67 IP67 IP67
Mechanical shock resistance g 30
Shock duration 11 ms
Characteristic values
Repetition accuracy of Sn % 1 1 1 1 1
Temperature drift of Sn % 10 10 10 10 10
Switching hysteresis of Sn % 15 15 15 15 15
Rated operating voltage 10 - 30 V DC 10 - 30 V DC 10 - 30 V DC 10 - 30 V DC 10 - 30 V DC
Residual ripple of Ue % 10 10 10 10 10
Operating current in the switched state at
24 V DC
Ib mA 10 10 10 20 10
Rated operational current Ie mA 100 100 100 100 100
Voltage drop at Ie Ud V 1.5 1.5 1.5 1.5 1.5
Switching frequency Hz 2000 2000 2000 1000 1000
Residual current due to the load in locked
state at 230 V AC or 24 V DC
Ir mA 0.01 0.01 0.01 0.01 0.01
Switching state indication LED Red Red Red Red Red
Protective functions Short-circuit protection
Protection against polarity reversal
Protection against wire breakage
Function 3-wire 3-wire 3-wire 3-wire 3-wire
Construction type
Design (outer dimensions) M8 x 1 M12 x 1 M12 x 1 M12 x 1 M18 x 1
Material Stainless steel Metal Metal Metal Metal
E57-18... E57-30...
E57-18GS... E57-18GU... E57-30GE... E57-30GS... E57-30GU...
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -25 - +70 -25 - +70 -25 - +70 -25 - +70 -25 - +70
Protection type IP67 IP67 IP67 IP67 IP67
Mechanical shock resistance g 30
Shock duration 11 ms
Characteristic values
Repetition accuracy of Sn % 1 1 1 1 1
Temperature drift of Sn % 10 10 10 10 10
Switching hysteresis of Sn % 15 15 15 15 15
Rated operating voltage 10 - 30 V DC 10 - 30 V DC 10 - 30 V DC 10 - 30 V DC 10 - 30 V DC
Residual ripple of Ue % 10 10 10 10 10
Operating current in the switched state at
24 V DC
Ib mA 10 20 10 10 20
Rated operational current Ie mA 100 100 100 100 100
Voltage drop at Ie Ud V 1.5 1.5 1.5 1.5 1.5
Switching frequency Hz 1000 500 500 500 200
Residual current due to the load in locked
state at 230 V AC or 24 V DC
Ir mA 0.01 0.01 0.01 0.01 0.01
Switching state indication LED Red Red Red Red Red
Protective functions Short-circuit protection
Protection against polarity reversal
Protection against wire breakage
Function 3-wire 3-wire 3-wire 3-wire 3-wire
Construction type
Design (outer dimensions) M18 x 1 M18 x 1 M30 x 1.5 M30 x 1.5 M30 x 1.5
Material Metal Metal Metal Metal Metal
Notes Further technical data can be found in the Online Catalogue at
