3/42 Sensors
E57 Global Series
2010 CA08103002Z-EN
www.eaton.comInductive Sensors
InductiveSensorsE57GlobalSeries
Technical data
InductiveSensorsE57GlobalSeries
E57-...(2-wire)
E57-12GS...A
E57-12GU...A
E57-18GS...A
E57-18GU...A
General
Standards
IEC/EN 60947-5-2
Ambient temperature
°C
-25 - +70
-25 - +70
-25 - +70
-25 - +70
Protection type
IP67
IP67
IP67
IP67
Mechanical shock resistance
g
30
Shock duration 11 ms
Characteristic values
Repetition accuracy of S
n
% 1
3
1
3
Temperature drift of S
n
% 10
10
10
10
Switching hysteresis of S
n
% 15
15
15
15
Rated operating voltage
20 - 250 V AC
20 - 250 V AC
20 - 250 V AC
20 - 250 V AC
Operating current in the switched
state at 24 V DC
I
b
mA
1.8
1.8
1.8
1.8
Rated operational current
I
e
mA
200
200
200
200
Voltage drop at I
e
U
d
V
8
8
8
8
Switching frequency
Hz
25
25
25
25
Min. load current
I
e
mA
5
5
5
5
Residual current due to the load in
locked state at 230 V AC or 24 V DC
I
r
mA
0.01
0.01
0.01
0.01
Switching state indication
LED Red
Red
Red
Red
Function
2-wire
2-wire
2-wire
2-wire
Construction type
Design (outer dimensions)
M12 x 1
M12 x 1
M18 x 1
M18 x 1
Material
Metal
Metal
Metal
Metal
E57-...(2-wire)
E57-18GE...A
E57-30GS...A
E57-30GU...A
General
Standards
IEC/EN 60947-5-2
Ambient temperature
°C
-25 - +70
-25 - +70
-25 - +70
Protection type
IP67
IP67
IP67
Mechanical shock resistance
g
30
Shock duration 11 ms
Characteristic values
Repetition accuracy of S
n
% 1
1
3
Temperature drift of S
n
% 10
10
10
Switching hysteresis of S
n
% 15
15
15
Rated operating voltage
20 - 250 V AC
20 - 250 V AC
20 - 250 V AC
Operating current in the switched
state at 24 V DC
I
b
mA
1.8
1.8
1.8
Rated operational current
I
e
mA
200
200
200
Voltage drop at I
e
U
d
V
8
8
8
Switching frequency
Hz
25
25
25
Min. load current
I
e
mA
5
5
5
Residual current due to the load in
locked state at 230 V AC or 24 V DC
I
r
mA
0.01
0.01
0.01
Switching state indication
LED Red
Red
Red
Function
2-wire
2-wire
2-wire
Construction type
Design (outer dimensions)
M18 x 1
M30 x 1.5
M30 x 1.5
Material
Metal
Metal
Metal
Notes
Further technical data can be found in the Online Catalogue at
www.moeller.net
