2/98 RMQ16 pilot devices
RMQ16
2010 CA08103002Z-EN
www.eaton.comRMQ16
Technical data
Contact
elements
Illuminated
pushbuttons
(maintained)
Illuminated
selector
pushbuttons
Indicator lights
General
Standards
IEC/EN 60947, VDE 0660
Lifespan, mechanical
Operations
x 10
6
> 100
> 30
> 3
–
Operating frequency
Operations/h
≦ 3600
≦ 1800
≦ 1800
–
Actuating force
N
3
4
–
–
Operating torque
Nm
–
–
≦ 0.2
–
Protection type,
IEC/EN 60529
IP20 with ISH2.8 IP65
IP65
IP65
Climatic proofing
Damp heat, constant as per IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
Open
°C
-25 - +60
-25 - +60
-25 - +60
-25 - +60
Encapsulated
°C
-25 - +40
-25 - +40
-25 - +40
-25 - +40
Mounting position
Any
Any
Any
Any
Mechanical shock resistance to IEC 60068-2-27
Shock duration 11 ms, half-sinusoidal
g
> 40
> 40
> 40
> 40
Terminal capacity
mm
2
0.5 - 1.0
0.5 - 1.0
0.5 - 1.0
0.5 - 1.0
Blade terminal
2.8 × 0.8 mm to DIN 46244
Flat pin bushing
2.8 × 0.8 mm to DIN 46247 and IEC 60760
Contacts
Rated impulse withstand voltage
U
imp
V AC
4000
800
800
800
Rated insulation voltage
U
i
V
250
250
250
250
Overvoltage category/pollution degree
III/3
III/3
III/3
III/3
Rated operational voltage
U
e
V AC
250
24
24
24
Control circuit reliability
At 24 V DC/5 mA
H
F
Fault probability < 10
-7
(i.e. 1 failure to 10
7
operations)
–
At 5 V DC/1 mA
H
F
Fault probability < 5 × 10
-6
(i.e. 1 failure to 5 × 10
6
operations)
–
Use of ISH insulated ferrule 2.8
On >24 V AC/DC recommended
On >50 V AC or 120 V DC mandatory, also on unoccupied blade terminals
Max. short-circuit protective device
Fuseless
Part no.
FAZ-B6/1
–
–
–
Fuse
gG/gL
A
10
–
–
–
Switching capacity
Rated operation current
AC-15
24 V
I
e
A
4
–
–
–
48 V
I
e
A
4
–
–
–
110 V
I
e
A
4
–
–
–
230 V
I
e
A
4
–
–
–
DC-13
24 V
I
e
A
3
–
–
–
42 V
I
e
A
1
–
–
–
60 V
I
e
A
0.8
–
–
–
110 V
I
e
A
0.5
–
–
–
220 V
I
e
A
0.2
–
–
–
