RESIDUAL CURRENT CIRCUIT BREAKERS
WITH OVERCURRENT PROTECTION (RCBO)
l
Single Pole
Type A
MCB Type C
Current rating (A) List No
6
701
C/063
10
701
C/103
16
701
C/163
20
701
C/203
32
701
C/323
40
701
C/403
50
701
C/503
l
Standard compliance BS EN 61009; IEC 1009.
l
Short circuit duty rating 16000A 240V 50Hz.
l
Terminal capacity up to 16mm
2
cable.
l
18
mm modular width
MCBs
73
C/10 73C/32
72
B/20 72C/10
RCBOs
MINIATURE CIRCUIT BREAKERS
l
Current
Single Pole
Rating (A) Type B Type C Type D
List No List No List No
6
70
B/06 70C/06 70D/06
10
70
B/10 70C/10 70D/10
16
70
B/16 70C/16 70D/16
20
70
B/20 70C/20 70D/20
32
70
B/32 70C/32 70D/32
40
70
B/40 70C/40 70D/40
50
70
B/50 70C/50 70D/50
63
70
B/63 70C/63 70D/63
l
BS EN 60898
l
Type B (3–5In), C (5–10In), D (10–20In) classification
l
Short circuit duty rating: Type B/C/D 16000A 240V/415V 50Hz
l
Terminal capacity up to 35mm
2
cable
l
18
mm modular width
Current
Double Pole
Rating (A) Type B Type C Type D
List No List No List No
6
72
B/06 72C/06 72D/06
10
72
B/10 72C/10 72D/10
16
72
B/16 72C/16 72D/16
20
72
B/20 72C/20 72D/20
32
72
B/32 72C/32 72D/32
40
72
B/40 72C/40 72D/40
50
72
B/50 72C/50 72D/50
63
72
B/63 72C/63 72D/63
l
BS EN 60898
l
Type B (3–5In), C (5–10In), D (10–20In) classification
l
Short circuit duty rating: Type B/C/D 16000A 240V/415V 50Hz
l
Terminal capacity up to 35mm
2
cable
l
18
mm modular width
l
Not for use within standard type A or B distribution boards
Current
Triple Pole
Rating (A) Type B Type C Type D
List No List No List No
6
73
B/06 73C/06 73D/06
10
73
B/10 73C/10 73D/10
16
73
B/16 73C/16 73D/16
20
73
B/20 73C/20 73D/20
32
73
B/32 73C/32 73D/32
40
73
B/40 73C/40 73D/40
50
73
B/50 73C/50 73D/50
63
73
B/63 73C/63 73D/63
l
BS EN 60898
l
Type B (3–5In), C (5–10In), D (10–20In) classification
l
Short circuit duty rating: Type B/C/D 16000A 240V/415V 50Hz
l
Terminal capacity up to 35mm
2
cable
l
18
mm modular width
